- Page 1 Assembly and Operating Instructions max. 150 kg ~ 60 Min. 66 kg L 153 | W 52 | H 158 TFZ99PRO21.01.05 Art. No. TF-Z99PRO-21 Taurus Smart Bike Z9.9 Pro...
- Page 2 Z9.9 Pro...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Further Functions Programmes 3.4.1 Quick-Start Programme/Target Programme 3.4.2 Pre-set Programmes 3.4.3 Interval Programme 3.4.4 Heart Rate Controlled Programmes 3.4.5 Watt Programme 3.4.6 Virtual Training Routes Multimedia and Software Updates... - Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT Z9.9 Pro...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Check your TFT console regularly for possible software updates. If available, make sure to carry out the updates. Technical Data TFT Display of Speed in km/h Rotations per minute Training time in min Training distance Calorie consumption in kcal Heart rate (when using the chest strap) Watt Resistance system:... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Electrical Safety
Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠... -
Page 10: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 12: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... - Page 13 Manual B-1 / E-1 C / O-1 D-1 / P-11 L-35L / L35R M / N L / R...
-
Page 14: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g. - Page 15 Step 2: Assembly of the Pedals Screw the right pedal (L-35R) into the thread of the pedal axis located on the right side of the main frame by turning it clockwise. Screw the left pedal (L-35L) into the thread of the pedal axis located on the left side of the main frame by turning it counter clockwise.
- Page 16 Step 3: Assembly of the Seat Post and Seat Insert the seat post (O-1) into the main frame (L). Attach the seat (P-11) to the seat post (O-1). Tighten the pre-assembled screw connection on the underside of the seat (P-11) with the tool. Z9.9 Pro...
- Page 17 Step 4: Assembly of the Handlebar Remove the pre-assembled screw (C-2) and limit piece (C-5). Loosen the pull pin (B-5) and slide out the upper slider (B-4). Attach the handlebar (B-1) to the upper slider (B-4) with two hex screws (Q-3) using the tool (fig. Slide the handlebar into position as shown in fig.
- Page 18 Step 5: Assembly of the Holder Tube Carefully pull the cable (C-3) through the handlebar post (C). ࣑ ATTENTION Make sure not to pinch the cables during the following steps. Mount the holder tube (E-1) to the the handlebar post (C) with two allen bolts (Q-7) and two flat washers (Q-8).
- Page 19 Step 6: Assembly of the Handlebar Post Connect the cables C-3 and L-12. ࣑ ATTENTION Make sure not to pinch the cables during the following steps. Attach the handlebar post (C) to the main frame (L). Fixate the handlebar post (C) by turning the lever clockwise on the right side of the main frame (L).
- Page 20 Step 7: Assembly of the Console Support Mount the console support (D-1) to the top of the holder tube (E-1) with one allen bolt (Q-5), two screw covers (Q-4) and one nut (Q-6). Tighten the screw connection with the tools. Z9.9 Pro...
- Page 21 Step 8: Assembly of the Console Remove the pre-assembled screws from the rear side of the console (A-1). Connect the console cable to the cable of the console supporting bar. ATTENTION Be careful not to pinch the cables during the following step. Mount the console (A) to the console support (D-1) with the previously removed screws (A-1).
- Page 22 Step 9: Alignment of the Feet If the floor is uneven, you can stabilize the equipment by turning the two setting screws under the main frame. Lift the equipment on the desired side and rotate the setting screws under the main frame. Rotate the screws clockwise in order to remove them and to raise the equipment.
-
Page 23: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display Display of the training time TIME Display range 0:00 - 99:99 SPEED Display of the current speed Display of the training distance... -
Page 24: Button Functions
Display of the heart rate zones HR Zone Display range very light, light, moderate, hard, maximum Display of the BAI consumption Display range 0 - 999 Display of the current revolutions per minute (RPM) Display range 0 - 999 Button Functions Start/Pause: Tap to start and/or pause the training Stop... -
Page 25: Further Functions
Further Functions Settings Here you will find all setting options. Volume Here you can adjust the volume. Brightness Here you can adjust the brightness. Timezone Here you can adjust the date or the current time zone. Wifi Here you can connect the console to a wifi network. Here you can connect the console to a Bluetooth chest Heart Rate strap. -
Page 26: Programmes
Programmes There are a variety of programmes available to you. These include Quick Start programme: Target programme: Pre-set programmes: Interval programme: Heart rate programmes: Watt programme: You can also set your own virtual training routes via Google Maps. Z9.9 Pro... -
Page 27: Quick-Start Programme/Target Programme
3.4.1 Quick-Start Programme/Target Programme Tap QUICK START in the main menu. Set the values for the desired distance, time and/or calories for your training. NOTICE You can set one or more parameters. The set values are counted down to 0, the others are counted up accordingly. -
Page 28: Pre-Set Programmes
3.4.2 Pre-set Programmes Tap PROGRAMS in the main menu. Set the desired training time. Select one of the 12 pre-set programmes. To start the training, tap START. You can manually adjust the resistance during the training. To pause the training, tap PAUSE. To stop the training, tap STOP. -
Page 29: Interval Programme
3.4.3 Interval Programme Tap INTERVAL in the main menu. Set the values for the desired number of cycles, time, resistance and revolutions per minute for your workout. To start the training, tap START. The workout starts with a 1-minute warm-up. You can manually adjust the resistance during the training. -
Page 30: Heart Rate Controlled Programmes
3.4.4 Heart Rate Controlled Programmes WARNING ⚠ Your exercise equipment is not a medical device. The heart rate measurement of this device may be inaccurate. A variety of factors can affect the accuracy of the heart rate display. The heart rate display is intended only as a training aid. - Page 31 To pause the training, tap PAUSE. To pause the training, tap STOP. → When the training is finished, a summary of the recorded training parameters is displayed.
-
Page 32: Watt Programme
3.4.5 Watt Programme Tap CONSTANT POWER in the main menu. Set the values for the desired training time, target wattage and target cadence for your training. To start the training, tap START. The resistance level is automatically adjusted according to the wattage you set. To pause the training, tap the following icon To stop the training, tap the following icon →... -
Page 33: Virtual Training Routes
3.4.6 Virtual Training Routes Tap MAP YOUR ROUTE in the main menu. After you have started this mode, you must determine your current position. To do this, tap the following icon To switch to the worldwide Google Maps view, tap the following icon NOTICE If you are within China, you can also select the default region by tapping the following icon Select your start position and tap until the following icon appears... - Page 34 Z9.9 Pro...
-
Page 36: Multimedia And Software Updates
Multimedia and Software Updates ࣑ ATTENTION Check your TFT-console regularly for possible software updates. If available, make sure to carry out the updates soon. If the updates are not carried out over a longer period of time, this can lead to technical problems with the console. To make sure the pre-installed apps are working correctly, they must be updated regularly as well. - Page 37 Example of an app Overview of apps and possible software updates...
-
Page 38: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 39: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 40: Error Codes And Troubleshooting
Error Codes and Troubleshooting The electronics of the equipment continuously carries out tests. In case of deviations, an error code appears on the display and normal operation is stopped for your safety. Please contact Sport-Tiedje for technical support. Z9.9 Pro... -
Page 41: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Display console Plastic covers Moisture of the felt brake Screws and cable connections... -
Page 42: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For indoor cycles this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat or silicone spray to keep moving parts in good shape. - Page 43 The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / indoor cycle Model Name: Smart Bike Z9.9 Pro 21 Article Number: TF-Z99PRO-21...
- Page 44 Parts List Name Qty. No. Name Qty. Console Cover for belt pulley Screws Screws Front handlebar assembly Right crank (B-1~B-11) Hex. screw Handlebar Nylon nut Upper cover for slider Flywheel assembly Hex. Screw (G-1~G-13) Upper slider for front Flywheel handlebar Aluminum flywheel Pull pin Small belt pulley...
- Page 45 Brake set L-13 Gear box Spring L-14 Screw Fixed spindle for brake L-15 Adjusting lever C-type L-16 Nylon nut Brake knob assembly L-17 Adjusting block for gear box 1 (K-1~K-14) L-18 Holder sheet for adjusting Brake knob lever Cover for brake knob L-19 Screw Brake bar...
- Page 46 Cap for front stabilizer T-shaped fixing sheet Allen bolt Briquetting for slider Flat washer Hex. screw Nylon nut P-10 Plastic strip for slider N (N-1~N-2) Rear stabilizer assembly P-11 Seat Rear stabilizer Hardware set (Q-1~Q-12) Cap for rear stabilizer Hex. screw Seat post assembly (O-1~O-17) Flat washer...
- Page 47 Exploded Drawing...
- Page 48 Z9.9 Pro...
- Page 49 WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
- Page 50 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
- Page 51 CONTACT TECHNIK TEKNIK OG SERVICE TECHNIQUE & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de �� �� Åbningstider kan findes på...
- Page 52 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
- Page 53 Notes...
- Page 54 Notes Z9.9 Pro...
- Page 56 Taurus Smart Bike Z9.9 Pro...
