• MAIN-A/-B UNIT
AF AMP
(IC55)
AF POWER AMP
CONTROLLER
(Q63)
PWR CTRL
(Q64)
1ST IF FILTER
(FI1)
1ST IF MIXER
(Q23)
IF DEMODULATOR IC
(IC3)
R5V LINE REGULATOR
(Q72)
AMP
(IC5)
AF CUSTOM IC
(IC2)
CLOCK AMP
(IC905)
(BOTTOM VIEW)
POWER LINE SW
(Q92)
2 - 2
RF AMP
(Q22)
TX POWER AMP
(Q1)
DRIVE AMP
(Q2)
PRE-DRIVE AMP
(Q3)
PLL BUFFER
(Q9)
RIPPLE FILTER
(Q15)
CPU
(IC51)
