Item Number Item Name Description Item Description The station should be installed by a competent person in accordance with national and local regulations. Zenitel takes no Turbine Extended IP Video Camera 1008317110 TEIV-1+ responsibility for damages caused by improper or inadequate...
Installation Item Description Comment CPU Module TEIV-1+/TEIV-4+ can be powered by PoE. This is done by connecting an Ethernet cable to the LAN port of the station and a PoE switch. 24VDC Card Reader Slot Only in use for TEIV-4+ 24VDC NB! If PoE is used, the station must be installed using a shielded Ethernet cable with grounding at the switch end.
Page 4
Mounting card readers The TEIV-4+ has a card reader slot, fitting either HID Signo 20 ReaderTerminal Strip or TWN4 Palon Compact LEGIC PCB. Do the following when mounting the card readers. HID Signo 20 ReaderTerminal Strip TWN4 Palon Compact LEGIC PCB Unscrew the Card Reader Bracket.
Flush mounting Insert the TA-34 Backbox into designated slot in the wall. Fasten the back box to the wall. For flush mounting the Turbine Extended, use the TA-34 Turbine Extended Flushmount Backbox. Plug the Ethernet cable into LAN port on the station. If the switch does not support PoE, a 24VDC Power Supply can be connected to the stations Power Input.
On-wall mounting Mount the TA-33 Backbox onto the wall using A4 socket head screws For mounting the Turbine Extenden on the Plug the Ethernet cable into LAN port on the station. If the switch wall, use the TA-33 Turbine Extended On- does not support PoE, a 24VDC Power Supply can be connected wall Backbox.
The Turbine Extended can operate in two different modes, IP Rating IP 66 Edge and SIP, depending on what kind of server it is registered to. Enter the link or scan the QR-code below to go to Zenitel IK Rating IK08 Wiki for configuration instructions.
Page 8
The WEEE Directive does not legislate that Zenitel, as a ‘producer’, shall collect ‘end of life’ WEEE. This ‘end of life’ WEEE should be recycled appropriately by the owner who should use proper treatment and recycling measures. It should not be disposed to landfill.
Page 9
Zenitel and its subsidiaries assume no responsibility for any errors that may appear in this publication, or for damages arising from the information therein. Zenitel, Vingtor-Stentofon and Phontech products are developed and marketed by Zenitel. The company’ s Quality Assurance System is certified to meet the requirements in NS-EN ISO 9001. Zenitel reserves the right to modify designs and alter specifications without notice. ZENITEL PROPRIETARY.
