- Page 1 ZDD-1 Zenitel Display Door - 1 Mounting & Installation Manual A100K12255 v1.3 zenitel.com...
-
Page 2: Safety Instructions
About Description This document serves as a mounting and installation guide for the ZDD-1 IP Video Front Station. For more information and instructions on configuration of the ZDD-1 go to wiki.zenitel. com. Item Number Item Name Description 1008510101 ZDD-1 Zenitel Display Door - 1... -
Page 3: Mounting Considerations
For future use. Max. current 900 mA. sharp edges, or areas where they might be pinched or crushed. The ZDD-1 must be powered by PoE+. This is done by connecting an Ethernet cable to Double Throw relay contact with 60W switching one of the LAN ports of the station and a PoE switch. - Page 4 When mounting the ZDD-1 use the TA-35, ZDD-1 Onwall backbox. Have the necessary cables ready before starting the mounting procedure. Hole for screw. Ensures that the ZDD-1 is locked to the backbox. Use 4mm or 5mm screws for mounting Z DD-1 Mounting & Installation Manual...
- Page 5 Pull the cable through the cable opening, leaving the cable length on Prepare the pre-punched holes and opening in the back box for wiring. the inside of the box as long as the Ethernet-cable printed on the back If only the power and network connection is required, utilize the hole of the box indicates.
- Page 6 Terminate all other wires according to the planned system setup Push the station down Make sure that all the wires are fitted under the u-shape when the A ‘click’ should be heard when the station is properly attached ZDD-1 is placed onto the back-box. ZDD-1 Mounting & Installation Manual...
- Page 7 Detach ZDD-1 from Onwall backbox Lock the station to the Onwall backbox If there is a need to lock the ZDD-1 to the onwall backbox, a screw can Before attempting to detach the intercom, ensure that any screws locking the station to be fitted into the dedicated hole located underneath the backbox as the backbox are removed.
-
Page 8: Contact Information
When the ZDD-1 is connected to the network, its IP address is automatically obtained from a DHCP server or an IP adress in the range 169.254.xx will be assigned. To prompt the station to announce its IP address, simply press the Touch Display located on the station. - Page 9 A100K12255 Zenitel and its subsidiaries assume no responsibility for any errors that may appear in this publication, or for damages arising from the information DOC.NO.: therein. Zenitel products are developed and marketed by Zenitel. The company’s Quality Assurance System is certified to meet the requirements in NS-EN ISO 9001.
