  • Page 1 USER HANDBOOK CIS 3100/3101/3102 MARITIME: COMMUNICATION SYSTEMS...
  • Page 3 Handbook page 1/73 Amendment Record Update doc no. 2019.8.6 A100K11941 / 4000017657 2014.06.25 CN00366: Update, Service and Warranty, Utilization 2011.04 Release p/n 4000017657 Version Issue Date Reason for issue Made by Approved by...
  • Page 4 Handbook page 2/73 CIS 310X Handbook contents: Handbook page: ……………………………………………………………..………....Service and Warranty …………………………………………………………………………………..…………… Utilization SYSTEM / MASTER STATIONS: COMMAND INTERCOM SYSTEM 310X  System Description ……...…………………………………………… 08300-007-DE .…………  Mechanical Layout, 3100, Master Station 5L ......…..… 08300-001-ML ..……  Mechanical Layout, 3101, Master Station 10L ......…..… 08300-002-ML ..…… ...
  • Page 5 Hanbook page 3/73  Mechanical Layout (wall mounting) .….………….……………….. 08900-001-ML-02 ...……  External Connection …........………………………… 08900-001-EC ..………… 9052, SUBSTATION, WATERTIGHT  Mechanical Layout …......….………….……………….. 02900-005-ML .…………  External Connection …........………………………… 02900-005-EC ..………… ACCESSORIES: 0005, HEADSET  Mechanical Layout …......….………….……………….. 87000-027-ML .………… ...
  • Page 6 Returned products in lack of such reference, will not be accepted by Zenitel and returned to Buyer at Buyer’s cost. g) The cost of the return shipment is to be covered by the Buyer. Zenitel will cover the cost of shipment for replacement parts.
  • Page 7 Hanbook page 5/73 Page 1 of 16...
  • Page 8 Handbook page 6/73 Doc.No.: 08300-007-DE CONTENTS. INTRODUCTION / INTRODUKSJON GENERAL DESCRIPTION / GENERELL BESKRIVELSE FACILITY LIST / FUNKSJONER OG MULIGHETER MOUNTING / INSTALLATION / SCREEN CONNECTION. MONTERING / INSTALLASJON OG SKJERM TERMINERING CABLE REQUIREMENTS / KRAV TIL KABEL SELECTIVE CALLS / SELEKTIVE ANROP ALL CALL / ALLEKALL(FELLESANROP) BRIDGE WING - EXTERNAL PAGING BROVING - EKSTERNT AKTIVERT ANROP...
  • Page 9 Hanbook page 7/73 1.0 INTRODUCTION / INTRODUKSJON Eng.: A command intercom system (CIS) consist of one MASTER station (3100 series), most often located on the ships bridge, and distributed SUBSTATIONS (9000 series) in cabins, engine room, engine control room a.s.o. The CIS may also comprise port and starboard side BRIDGE WING stations.
  • Page 10 Handbook page 8/73 Doc.No.: 08300-007-DE CIS leveres som følger: MASTER STASJONER: - 3100 CIS MASTER STASJON maks. 5 linjer. Forsterker kapasitet 10 W. - 3101 CIS MASTER STASJON. maks. 10 linjer. Forsterker kapasitet 20 W. - 3102 CIS MASTER STASJON. maks. 20 linjer. Forsterker kapasitet 40 W. UNDERSTASJONER/UTSTYR: - 9001 understasjon for lugar/ oppholdsrom.
  • Page 11 Hanbook page 9/73 Doc.No.: 08300-007-DE - External loudspeaker output connections. OPTIONS. - Line engagement time out. - Optional extra signal organ output for all lines (up to 10) - Optional line amplifier connection. - Gooseneck/handheld microphone connection. No.: CIS 3100: - Tilkobling for 5 understasjoner.
  • Page 12 Handbook page 10/73 Doc.No.: 08300-007-DE FIGURE 1 / FIGUR 1 MOUNTING / INSTALLATION / SCREEN CONNECTION MONTERING / INSTALLASJON OG SKJERMTERMINERING Eng.: MOUNTING: The master stations 3100/3101/3102 is delivered for flush mounting. On request the units may be delivered with wall-mounting box. (option) Front plate dimensions 3100 and 3101: 144 x 144 mm.
  • Page 13 Hanbook page 11/73 Doc.No.: 08300-007-DE The master station location/ orientation with regards to the operator must be taken especially into consideration. Please note the gooseneck mic (if installed) is "close talk". A close talk microphone has the ability to reduce surrounding noise to a minimum.
  • Page 14 Handbook page 12/73 Doc.No.: 08300-007-DE FIGURE 2 / FIGUR 2 Eng.: The cable outer screens is to be terminated as shown. Conductive type of cable ties is recommended to obtain best possible screen connections. No.: Kabelens ytterskjerm skal termineres som vist. Festebånd av ledende materiale bør benyttes for å oppnå best kontakt mellom skjerm og chassis.
  • Page 15 Hanbook page 13/73 Doc.No.: 08300-007-DE Consult drawings 97301-007-EC (CIS 3100), 97301-002-EC (CIS 3101) and 97301-013-EC (CIS 3102) for further cabling information. No.: Til understasjoner: ett par revolvert, utvendig skjermet. Ved ekstra signal organ: et ekstra par. Til broving: to par, individuelt revolvert, utvendig skjerm. Kraft kabler: ett par, jord.
  • Page 16 Handbook page 14/73 Doc.No.: 08300-007-DE 6.3 A SUBSTATION ANSWER THE CALL FROM THE MASTER / UNDERSTASJONEN SVARER PÅ ANROP FRA HOVEDSTASJON Eng.: When the attention tone is heard in the loudspeaker and / or the extra signal organ is activated: - Press the talk-key and answer the call.
  • Page 17 Hanbook page 15/73 Doc.No.: 08300-007-DE 6.7. TERMINATING THE CONVERSATION / AVSLUTTE SAMTALEN Eng.: The conversation is terminated by de-activating the line: - Operate the line key once more. The line indicator led turn green half-light intensity. (backlight) No.: Samtalen avsluttes ved å legge linjen ut igjen: - Trykk linjeknappen en gang til.
  • Page 18 Handbook page 16/73 Doc.No.: 08300-007-DE - The master station normally has first priority. - If the external emergency paging is enabled this will have an intermediate first priority and override existing calls. After this first priority override activation the master station regains priority and can place calls of any type. No.: - Hovedstasjonen har normalt første prioritet.
  • Page 19 Hanbook page 17/73 Doc.No.: 08300-007-DE Current drain / strømtrekk: 2 A max. Line capacity / linjekapasitet: 10 lines. Power amp. capacity / forsterkerkapasitet: 20 W total Up to 10 W per line. Frequency range / frekvens område: Better than 400-6000 Hz (-3dB) Distortion / forvrengning: Better than 2.5% typ.
  • Page 20 Handbook page 18/73 Doc.No.: 08300-007-DE 14.0 SYSTEM BOARD 97301-001 (CIS 3100/3101) STRAPPING AND CONNECTION POINT LOCATIONS / LOKALISERING AV LINKER OG KONTAKTPUNKTER. J2 Terminal / pin No. - J2 Terminal / pin. nr. Function / Equipment Funksjon / tilkoblet utstyr 1 &...
  • Page 21 Hanbook page 19/73 Doc.No.: 08300-007-DE FIGURE 3 / FIGUR 3 ST 3 PROGRAM SELECTOR NORM OPEN CLOSED WHEN STB BW INPUT IS USED F. ALLCALL ST1 CLOSED WHEN EXT. MIC. IS USED ST2 CLOSED WHEN INTERNAL MIC IS USED CONNECTION PIN 7/8 FOR EXT. MIC PTT CONNECTION PIN 5/6 FOR EXT.
  • Page 22 Handbook page 20/73 Doc.No.: 08300-007-DE 15.0 SYSTEM BOARD 97301-011 (CIS 3102) STRAPPING AND CONNECTION POINTS LOCATION / LOKALISERING AV LINKER OG KONTAKTPUNKTER. J3 Terminal / pin No. - J3 Terminal / pin. nr. Function / Equipment Funksjon / tilkoblet utstyr 1 &...
  • Page 23 Hanbook page 21/73...
  • Page 24 Handbook page 22/73...
  • Page 25 Hanbook page 23/73...
  • Page 26 Handbook page 24/73...
  • Page 27 Hanbook page 25/73...
  • Page 28 Handbook page 26/73...
  • Page 29 Hanbook page 27/73...
  • Page 30 Handbook page 28/73...
  • Page 31 Hanbook page 29/73...
  • Page 32 Handbook page 30/73...
  • Page 33 Hanbook page 31/73...
  • Page 34 Handbook page 32/73...
  • Page 35 Hanbook page 33/73...
  • Page 36 Handbook page 34/73...
  • Page 37 Hanbook page 35/73 ZENITEL AS...
  • Page 38 Handbook page 36/73...
  • Page 39 Hanbook page 37/73 ZENITEL AS ZENITEL AS...
  • Page 40 Handbook page 38/73...
  • Page 41 Hanbook page 39/73 ZENITEL AS ZENITEL AS...
  • Page 42 Handbook page 40/73...
  • Page 43 Hanbook page 41/73 ZENITEL AS ZENITEL AS...
  • Page 44 Handbook page 42/73...
  • Page 45 Hanbook page 43/73 ZENITEL AS ZENITEL AS...
  • Page 46 Handbook page 44/73...
  • Page 47 Hanbook page 45/73...
  • Page 48 Handbook page 46/73...
  • Page 49 Hanbook page 47/73 ZENITEL AS ZENITEL AS...
  • Page 50 Handbook page 48/73...
  • Page 51 Hanbook page 49/73 ZENITEL AS ZENITEL AS...
  • Page 52 Handbook page 50/73...
  • Page 53 Hanbook page 51/73...
  • Page 54 Handbook page 52/73...
  • Page 55 Hanbook page 53/73...
  • Page 56 Handbook page 54/73...
  • Page 57 Hanbook page 55/73...
  • Page 58 Handbook page 56/73...
  • Page 59 Hanbook page 57/73...
  • Page 60 Handbook page 58/73...
  • Page 61 Hanbook page 59/73...
  • Page 62 Handbook page 60/73...
  • Page 63 Hanbook page 61/73...
  • Page 64 Handbook page 62/73...
  • Page 65 Hanbook page 63/73...
  • Page 66 Handbook page 64/73 HP-10(T) HEAD OFFICE, NORWAY GERMANY ENGLAND DNH AS DNH WW Ltd DNH GmbH DNH Speakers Inc Phone....+ 47 35 98 56 00 Phone……. + 44 1908 275 000 Phone… + 49 040 6569 30-0 Phone... + 1 484 494 5790 Fax……….....
  • Page 67 Hanbook page 65/73 HP-15(T) HEAD OFFICE, NORWAY GERMANY ENGLAND DNH AS DNH WW Ltd DNH GmbH DNH Speakers Inc Phone....+ 47 35 98 56 00 Phone……. + 44 1908 275 000 Phone… + 49 040 6569 30-0 Phone... + 1 484 494 5790 Fax……….....
  • Page 68 Handbook page 66/73 HP-20(T) HEAD OFFICE, NORWAY GERMANY ENGLAND DNH AS DNH WW Ltd DNH GmbH DNH Speakers Inc Phone....+ 47 35 98 56 00 Phone……. + 44 1908 275 000 Phone… + 49 040 6569 30-0 Phone... + 1 484 494 5790 Fax……….....
  • Page 69 Hanbook page 67/73 ZENITEL AS ZENITEL AS...
  • Page 70 Handbook page 68/73...
  • Page 71 Hanbook page 69/73...
  • Page 72 Handbook page 70/73...
  • Page 73 Hanbook page 71/73...
  • Page 74 Handbook page 72/73...
  • Page 75 Hanbook page 73/73 DSP-15EExmN HEAD OFFICE, NORWAY ENGLAND GERMANY DNH AS DNH WW Ltd DNH GmbH DNH Speakers Inc Phone....+ 47 35 98 56 00 Phone……. + 44 1908 275 000 Phone… + 49 040 6569 30-0 Phone... + 1 484 494 5790 Fax……….....
  • Page 76 Zenitel and its subsidiaries assume no responsibility for any errors that may appear in this publication, or for damages arising from the information therein. Phontech products are developed and marketed by Zenitel. The company’s Quality Assurance System is certified to meet the requirements in NS-EN ISO 9001. Zenitel reserves the right to modify designs and alter specifications without notice. ZENITEL PROPRIETARY. This document and its supplementing elements, contain Zenitel or third party information which is proprietary and confidential.
