Zenitel ZSD-1 Installation Manual

About
This document serves as a mounting and installation guide for the ZSD-1 Zenitel Slim Door Intercom.
For more information and instructions on configuration of the ZSD-1 go to wiki.zenitel.com.
Item Number Item Name
1008325010 ZSD-1
Safety Instructions
This manual contains important instructions that must be followed. These instructions are
intended to ensure that the product is mounted and installed correctly to avoid equipment damage
or property loss. Familiarize yourself with the components and follow the instructions step by step.
A note symbol indicates that extra care must be taken. Damage to
equipment can occur, or it may not function as intended. Please read all
warnings before installing this product.
Installation should only be carried out by qualified personnel with experience in low-voltage
electrical systems. Ensure that the installer is familiar with local electrical codes and regulations.
Make sure that the installation complies with all applicable local, regional, and national regulations
regarding electrical installations and low-voltage systems.
After installation, conduct a thorough test of the intercom to ensure proper functionality. Test
communication, audio quality, and any additional features according to the provided instructions.
Zenitel takes no responsibility for damages caused by improper or inadequate
ZSD-1 Mounting & Installation Manual
Mounting considerations
Check the specification of the product for the installation environment.
Choose a suitable location for the intercom system, try to minimize exposure to water sources, direct
sunlight, extreme temperatures, and corrosive substances.
The ZSD-1 must be correctly mounted with the camera positioned on top to
maintain the IP rating and ensure proper functionality of the mounting hooks.
Mount the intercom at a height and angle that provide optimal comfort for users during interaction.
Consider the natural standing or sitting positions of users and adjust the mounting accordingly. It is
recommended to mount the station so that the call button is positioned at a height of approximately 120
cm. This is recommended and necessary to be compliant with accessibility regulations.
Installation
Prior to commencing the installation procedure, deactivate the power supply to both the intercom
system and its associated devices. This precautionary measure ensures optimal safety throughout the
installation process.
Ensure that all cables are properly routed and secured to prevent tripping
hazards or damage. Avoid placing cables near heat sources, sharp edges, or
areas where they might be pinched or crushed.
The ZSD-1 must be powered by either PoE or PoE+. This is done by connecting an Ethernet cable to the
LAN ports of the station and a PoE switch.
To comply with EMC regulations, the ZSD-1 must be installed with a shielded
Ethernet cable with grounding at the switch end.
ZSD-1 Mounting & Installation Manual
Description
Zenitel Slim Door Intercom
installation.
1
2
