- Page 1 IP Desk Master Stations Getting Started Guide A100K12187...
-
Page 2: Installation
IP Desk Master with Handset V2_P 1008401190 IPDMHB-V2_P IP Desk Master with Handset (black)-V2_P For more information and instructions on configuration of the IPDM-V2_P please go to https://wiki.zenitel.com/wiki/IP_Desk_Master_-V2-P. For more information and instructions on configuration of the IPDMH-V2_P and IPDMHB-V2_P please go to https://wiki.zenitel.com/wiki/IP_Desk_... - Page 3 Configuration The station can operate in different modes: ICX-AlphaCom, Edge and SIP. The default mode is Edge. The description in the rest of this document uses the ICX-AlphaCom mode as an example. There are two ways of configuring the IP Desk Master Station, either via the station keypad or via a web browser.
-
Page 4: Station Info
The Main Menu Not configured To enter the setup menu: Press the Setup key Setup Enter the default password 1851 by using the station keypad - Enter password Press the OK key 1851 A menu with six options will be displayed. - Main Menu - Use the two arrow keys in the middle Station Info -->... -
Page 5: Station Mode
Station Mode - Station Mode - <*> ICX-AlphaCom < > Edge Select Station Mode followed by ICX- < > SIP AlphaCom Back ICX Settings - ICX Settings - ICX IP: 169.254. 1 .5 Request Dir No: 2525 Set the IP address of ICX-AlphaCom that the station shall connect to, and the directory number of the station. -
Page 6: Configuration Via Web Browser
Configuration via Web Browser IP Desk Master Station Web Interface The IP Desk Master Station features an embedded web server, which allows users to login via a standard web browser. At commissioning, the IP station needs to be configured to enable it to subscribe to an ICX- AlphaCom server. -
Page 7: Station Main Settings
Station Main Settings Click Station Main > Main Settings to access the page for configuring station mode and IP parameters. Under Mode, select ICX-AlphaCom. Registration Settings. Enter the IP address of the ICX-AlphaCom server in which the IP station is to be a subscriber in the ICX-AlphaCom IP-addresses field. - Page 8 IP Desk Master with Handset V2_P. The WEEE Directive does not legislate that Zenitel, as a ‘producer’, shall collect ‘end of life’ WEEE. This ‘end of life’ WEEE should be recycled appropriately by the owner who should use proper treatment and recycling measures.
- Page 9 A100K12187 Zenitel and its subsidiaries assume no responsibility for any errors that may appear in this publication, or for damages arising from the information therein. Zenitel, Vingtor-Stentofon and Phontech products are developed and marketed by Zenitel. The company’ s Quality Assurance System is certified to meet the requirements in NS-EN ISO 9001.
