Value
Remote input
Mode
Input threshold
Enabled
Enable voltage
Enable delay
Disable voltage
Disable delay
Instant disable
Sleep delay
Charger
Battery type**
Method
Max output (limit) Maximum output (charge) current
Max input (limit)
Current ramp up
Temp.
compensate
Bulk
Bulk voltage
Max bulk time
Min bulk time
Start bulk time
Mac Plus – User and Installation Manual
Meaning
Active low: active when the input
voltage is 0 - 0.5 V
Active high: active when the input
voltage is 3 - 32 V
Not used: always active
Enabled: input voltage thresholds
are active
Disabled: input voltage thresholds
are not active
Enable input voltage
Enable delay
Disable input voltage
Disable delay
Disable input voltage, no delay
Delay before the Mac Plus
switches to sleep mode
Selection of pre-set charge
settings. Individual adjustments
are only possible if "User defined"
is selected here.
Charge method
Maximum input current
Charge current ramp up after
enabling the charger.
Temperature compensation for
charge voltage
Bulk voltage
Maximum bulk time
Minimum bulk time
Start bulk timer
Factory setting Adjustable range
Active high Not used, Active low,
Active high
Enabled Enabled, Disabled
12.50 V* 8-16 V*
2 s 0-300 s
12.00 V* 8-16 V*
300 s 0-300 s
11.00 V* 8-16 V*
300 s 0-3600 s
Flooded Flooded, Gel, AGM,
LiIon, User defined
3-Step+ 3-Step+ (IUoU),
Constant voltage
(13.25 V*)
50 A / 30 A 0-50 A / 0-30 A
50 A / 30 A 0-50 A / 0-30 A
5 A/s 0-50 A/s
-0.030 V/°C -0.1 - +0.1 V
14.25 V* 8-15 V*
480 min 0-1440 min
120 s 0-240 s
13.25 V* 8-15 V*
