4. Installation instructions

In addition to the Mac Plus the delivery includes:
•
Battery temperature sensor;
•
Drop cable CZone/MB (1m);
•
MasterBus Terminator;
•
User and installation manual.
Installation steps:
1 Place and mount the Mac Plus, see chapter 5;
2 Connect the Mac Plus, see chapter 6;
Configure the Mac Plus, see chapters 7 and 9 or 10.
3
CAUTION
Read the entire manual before installing the Mac Plus. Keep the manual at a safe
location for future reference.
•
Operating temperature range: -20 up to +60 ºC, >40 ºC derating power
[-4 up to +140 ºF, >104 ºF derating power].
•
Never use the Mac Plus at a location where there is danger of gas or dust explosions.
•
Mount the Mac Plus in such a way that obstruction of the airflow through the heatsink is
prevented. This device requires a minimum of 10 cm (4") of clearance on every side.
•
Do not mount the Mac Plus straight above batteries that might release corrosive sulphur fumes.
•
Be sure that the output of the supplying source is switched off during installation. Also be sure
that no load is connected to the batteries during installation, to prevent hazardous situations.
•
Use cables with an appropriate size, see the following table.
Model
12/12-50
12/24-30
24/12-50
24/24-30
24/24-50
Mac Plus – User and Installation Manual
Recommended wire sizes DC input/output
Minimum wire size Input
2
16 mm [
AWG
2
16 mm [
AWG
2
10 mm [
AWG
2
10 mm [
AWG
2
16 mm [
AWG
6]
6]
8]
8]
8]
Min. 3 Nm – max. 5 Nm
Minimum wire size Output
2
16 mm [
AWG
2
10 mm [
AWG
2
16 mm [
AWG
2
10 mm [
AWG
2
16 mm [
AWG
11
6]
8]
6]
8]
6]
