Omcan Aurora FR-CN-1372E-HC Instruction Manual page 17

Model RE-CN-0021E-HC
Item No. Description
AJ129 Cabinet for 59024
AJ130 Control Panel for 59024
AF027 Front Grill for 59024
AA954 Upper Right Hinge Holder for 59024
AA956 Bottom Right Hinge Holder for 59024
AA955 Left/Right Spring Hinge for 59024
Bottom Cover for Reversible Door for
AA972
59024
AJ131 Door for 59024
AA958 Gasket for 59024
AG442 K Clip for 59024
AG443 K Strip for 59024
AA975 Shelf for 59024
AF029 Leg Supporter for 59024
Left Track for Assembling Panel for
AF040
59024
Right Track for Assembling Panel for
AF041
59024
AG445 Evaporator for 59024
AG446 Inner Drain Pan for 59024
Left Evaporator Fan Motor Holder for
AG447
59024
59024
Position Item No. Description
1 AG448 Evaporator Fan Motor for 59024
2 AB109 Thermostat for 59024
3 AA124 Power Switch for 59024
4 AG449 Evaporator Cover for 59024
5 AG450 Back Grill for 59024
6 AB977 Door Switch for 59024
7, 8 AA197 Lock for 59024
9 26246 Caster with Brake for 59024
10 26247 Caster without Brake for 59024
11 AG451 Drain Plug for 59024
12 AB169 Foaming Hole Cover for 59024
13 AA216 Drain Tube for 59024
14 AJ132 Light Components for 59024
15 AA805 Power Cord for 59024
Compressor Unit Installation Board for
16 AG452
59024
17 AA986 Condenser for 59024
18 AG453 Air Guide Sheet for 59024
Condenser/Evaporator Fan Motor Blade
19 AA764
for 59024
Parts Breakdown
Position Item No.
20, 36 AB595
21 AB594
22 AA874
23 AI386
24 AI392
25 AG455
26, 45 AG462
27 AG463
28 AG464
29 AA959
30 AG465
31 AA969
32 AG466
33 AG467
34 AG468
35 AG469
37 AG470
38, 51 AG471
17
Description Position
Filter Fixer for 59024 39
Filter D25x160-B for 59024 40
Outer Drain Pan for 59024 41
Compressor for 59024 42
Compressor Starting Components for
43
59024
Temperature Sensor of Cabinet Inside
44
for 59024
Baffle of Suction Line for 59024 46
Back Grill Fixer for 59024 47
Control Panel Fixer for 59024 48
Hinge for 59024 49
Lock Bolt for 59024 50
Drain Hose for 59024 52
Elbow Pipe for 59024 53
Evaporator Fan Motor Cover for 59024 54
Limited Block of Installation Board for
55
59024
Compressor Unit Handle for 59024 56
Condenser Fan Motor Holder for 59024 57
Right Evaporator Fan Motor Holder
58
for 59024
