Omcan Aurora FR-CN-1372E-HC Instruction Manual page 13

Model FR-CN-0737E-HC
Item No. Description
AF024 Cabinet for 59023
AI316 Control Panel for 59023
AF026 Control Panel Fixer for 59023
AF027 Front Grill for 59023
AA954 Upper Right Hinge Holder for 59023
AA955 Left/Right Spring Hinge for 59023
AA956 Bottom Right Hinge Holder for 59023
AI317 Door for 59023
AA958 Gasket for 59023
AA959 Hinge for 59023
AA197 Lock for 59023
AF028 Lock Bolt for 59023
AF029 Leg Supporter for 59023
AF825 Evaporator Fan Motor for 59023
AA962 Blade of Evaporator Fan Motor for 59023
AF031 Evaporator Fan Motor Holder for 59023
AF032 Right Air Guide Sheet for 59023
AF033 Left Air Guide Sheet for 59023
AI318 Evaporator for 59023
AF034 Inner Drain Pan for 59023
59023
Position Item No. Description
1 AF035 Inner Drain Pan Fixer for 59023
2 AA969 Drain Hose for 59023
3 69703 Elbow Pipe for 59023
4 AA970 Light Components for 59023
5 AF037 Evap Fan Motor Cover for 59023
Bottom Cover for Reversible Door for
6 AA972
59023
7 26884 K Clip for 59023
8 AA809 K Strip for 59023
9 AA975 Shelf for 59023
10 AF038 Evaporator Cover for 59023
Limited Block of Installation Board for
11, 61 AF039
59023
12 AF040 Left Track for Assembling Panel for 59023
Right Track for Assembling Panel for
13 AF041
59023
Compressor Unit Installation Board for
14 AF042
59023
15 AI319 Compressor for 59023
Compressor Starting Components for
16 AI320
59023
17 AB595 Filter Fixer for 59023
18 AB594 Filter for 59023
19 AA249 Condenser Fan Motor Cover for 59023
Condenser/Evaporator Fan Motor Blade
20 AA764
for 59023
Parts Breakdown
Position Item No.
21 AI321
22 AB959
23 AF055
24 AF045
25 AA989
26, 31 AA124
27 AI322
28 AB977
29 AF046
30 26247
32 26246
33 AA993
34 AA379
35 AA864
36 AB084
37-40, 57 AA865
41 AA867
42 AA216
43 AA135
44
13
Description Position
Condenser Fan Motor for 59023 45
Outer Drain Pan for 59023 46
Condenser for 59023 47
Back Grill Fixer for 59023 48
Back Grill for 59023 49
Power Switch for 59023 50
Thermostat for 59023 51
Door Switch for 59023 52
Drain Plug for 59023 53
Caster without Brake for 59023 54
Caster with Brake for 59023 55
Power Plug Fitting Base for 59023 56
Temperature Probe for 59023 58
Drain Pan Heater for 59023 59
Evaporator Temperature Sensor for
60
59023
Defrost Heater for 59023 62
Drain Hose Heater for 59023 63
Drain Tube for 59023 64
Power Cord for 59023 65
