Omcan Aurora FR-CN-1372E-HC Instruction Manual page 15

Model FR-CN-1372E-HC
Item No. Description
AJ133 Cabinet for 59025
AJ134 Control Panel for 59025
AF048 Front Grill for 59025
AJ135 Right Door for 59025
AB029 Gasket for 59025
AA954 Upper Right Hinge Holder for 59025
AA956 Bottom Right Hinge Holder for 59025
AA955 Left/Right Spring Hinge for 59025
AJ136 Left Door for 59025
AB032 Upper Left Hinge Holder for 59025
AB033 Bottom Left Hinge Holder for 59025
AG442 K Clip for 59025
AG443 K Strip for 59025
AG550 Back Brackets for 59025
AA975 Shelf for 59025
61471 Leg Supporter for 59025
Left Track for Assembling Panel for
AF040
59025
Right Track for Assembling Panel for
AF041
59025
AJ157 Evaporator for 59025
AG552 Inner Drain Pan for 59025
Left Evaporator Fan Motor Holder for
AG447
59025
AG448 Evaporator Fan Motor for 59025
59025
Position Item No. Description
1 AG553 Evaporator Cover for 59025
2 27186 Carel Controller IR33 for 59025
3 AA124 Power Switch for 59025
4 AA197 Lock for 59025
5, 10 AB977 Door Switch for 59025
6 AG554 Back Grill for 59025
7 26246 Caster with Brake for 59025
8, 13 26247 Caster without Brake for 59025
9 AG451 Drain Plug for 59025
11 AB169 Foaming Hole Cover for 59025
12 AA216 Drain Tube for 59025
14 AJ132 Light Components for 59025
15 AA805 Power Cord for 59025
Temperature Sensor of Cabinet Inside
16 AG455
for 59025
Compressor Unit Installation Board for
17 AG452
59025
18 AH690 Condenser for 59025
19 AM510 Condenser Fan Motor for 59025
20 AA814 Condenser Fan Motor Blade for 59025
21 AB077 Condenser Fan Cover for 59025
22 AB595 Filter Fixer for 59025
23 AB594 Filter D25x160-B for 59025
24 AB970 Outer Drain Pan for 59025
Parts Breakdown
Position Item No.
25 AM511
26 AG558
27 AJ151
28, 49 AB376
29 AM512
30 AJ162
31 AG462
32 AG463
33 AG464
34 AA959
35 AG465
36 AA764
37 AA969
38 AG466
39 AG467
40 AG468
41 AJ155
42 AG469
43 AG471
44 AJ156
45
46
15
Description Position
Compressor for 59025 47
Cabinet Supporter for 59025 50
Evaporator Temperature Sensor for
51
59025
Thermostat for 59025 52
Drain Hose Heater for 59025 53
Defrost Heater for 59025 54
Baffle of Suction Line for 59025 55
Back Grill Fixer for 59025 56
Control Panel Fixer for 59025 57
Hinge for 59025 58
Lock Bolt for 59025 59
Condenser/Evaporator Fan Motor Blade
60
for 59025
Drain Hose for 59025 61
Elbow Pipe for 59025 62
Evaporator Fan Motor Cover for 59025 63
Limited Block of Installation Board for
64
59025
Decompression Valve for 59025 65
Compressor Unit Handle for 59025 66
Right Evaporator Fan Motor Holder
67
for 59025
Fuse for 59025 68
