#EMG2000 MAGNUM™ LED DIRECT CONNECT Lightbar
DIRECT CONNECT FLASH PATTERNS AND WIRE FUNCTIONS
40Amp FUSE
(Customer Supplied)
GROUND
GROUND
# Pattern Name Sequence
1 Quint Alternating
2 Warp Alternating
3 Inter-Cycle Flash Alternating
4 Quad Flash Alternating
5 RoadRunner Alternating
6 RoadRunner Simultaneous
7 Slow Runner Alternating
8 Slow Runner Simultaneous
9 Q-Switch Variable
10 Single, Steady Burn Steady Burn
11 Quad, Steady Burn Steady Burn
12 Warp, Steady Burn Steady Burn
13 Nothing, Steady Burn Steady Burn
14 E-Single Flash Alternating
15 E-Double Flash Alternating
16 E-Single Flash Simultaneous
17 E-Double Flash Simultaneous
18 Warp 1,2,3,4 Variable
19 Warp 2,3,1 Variable
20 Warp 3,2,1 Variable
21 Steady Burn Steady Burn
*fpm=Flashes per Minute
**fps=Flashes per Second
10
DRAIN WIRE
BLACK 12 GA.
fpm* fps** Wire Color
70 1.18 Pink
350 5.88 Orange
- -
Violet
80 1.35 Red
115 1.92 Tan
115 1.92 Black
70 1.16
White
70 1.16
Brown
- - Gray
115 1.92 Blue
80 1.35 Green
350 5.88
Yellow
- -
LED Work Light/Take down Flash Pattern
125 2.08
1 Road Runner Alternating
125 2.08
2 PowerPulse
125 2.08
3 Q-Switch
125 2.08
4 ETM
- -
5 Steady Burn
- -
- -
- -
Standard Functions
Work Lights/Take Downs
Alley Driver Steady Burn
Left Turn
Stop
Corners
Low Power
Pattern Select
Alley Passenger Steady Burn
Inboards 2, 3
Inboards 1
Right Turn
Tail
115 1.92
Alternating 180 3.00
Variable - -
Simultaneous 214 3.57
Steady Burn - -
Note: Alley Driver & Passenger
are Steady Burn only
EMG2000-DC 0419
