Preparations

1. If you have a waste pipe outside, the cooker hood can be connected using
extraction duct (enamel, aluminum, flexible pipe or a fire-resistant material
with an inner diameter of 150 mm), see the following picture:
2. Before installation, switch off the unit and unplug the power cord from the wall
socket.
3. Installation of the cooker hood should be right on the top of the stove with a
minimum distance of 65 cm and a height of maximum 75 cm from the surface
of the stove.

PART 3: INSTALLATION

5
