User Guide
ORDERING INFORMATION
Table 4. EVAL-ADAQ4001PMDZ and EVAL-ADAQ4003PMDZ Bill of Materials
Qty. Reference Designator
1 R16
3 R8, R17, R31
2 R18, R21
4 R2 to R5
5 R6, R20, R22, R24, R25
24 R7, R23, R26 to R30, R35 to R37, R40,
R43 to R48, R51 to R55, R57, R60
2 R32, R34
1 R33
1 R9
1 RN1
1 U1
1 U2
1 U3
2 U4, U7
1 U5
1 U6
1 A1
analog.com
Description
60.4 kΩ resistor, precision thick film chip
698 kΩ resistors, precision thick film chip
61.9 kΩ resistors, precision thick film chip Yageo
42.2 kΩ resistors, precision thick film chip Panasonic
0 Ω film resistors, surface-mount device
(SMD), 0603
0 Ω film resistors, SMD, 0402, jumper
short
200 kΩ resistors, precision thick film chip
95.3 kΩ resistor, precision thick film chip
3.3 kΩ resistor, precision thick film chip
Resistor network quad matched
Ultralow noise, high accuracy, 5.0 V
voltage reference
Dual positive and negative low noise low
dropout (LDO) regulator
1 A/0.6 A, dc-to-dc switching regulator
with independent positive and negative
outputs
High voltage, low noise, low distortion,
unity-gain stable, high speed op amps
16-bit/18-bit, 2 MSPS, µModule data
acquisition solution in ball grid array
Low dropout, low noise regulator
Programmable gain drift instrument
amplifier
EVAL-ADAQ4001/EVAL-
Manufacturing
Panasonic
Panasonic
Panasonic
Panasonic
Panasonic
Panasonic
Panasonic
Analog Devices, Inc.
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Analog Devices
ADAQ4003
Part No.
ERJ-2RKF6042X
ERJ-2RKF6983X
RC0402FR-0761K9L
ERJ-2RKF4222X
ERJ-3GEY0R00V
ERJ-2GE0R00X
ERJ-2RKF2003X
ERJ-2RKF9532X
ERJ-2RKF3301X
LT5400BHMS8E-4#PBF
ADR4550BRZ
LT3032IDE#PBF
ADP5070ACPZ-R7
ADA4898-1YRDZ
ADAQ4001/ADAQ4003
LT3023IDD#PBF
AD8251ARMZ
Rev. B | 30 of 31
