The siren must be installed on the wall, high above the floor, at a hard to access location,
so as to minimize the risk of tampering. Make sure that some free space is left above the
siren (at least 2.5 cm). Otherwise, it will be impossible to replace the cover.
1. Remove the cover locking screws.
2. Lift up the enclosure cover by approx. 60º and remove it (Fig. 3).
3. Install the battery. The leftmost LED will start flashing every second to indicate that the
battery initialization procedure has begun. Given the specific character of the battery,
it must be properly initialized to reach the required power supply parameters. When the
battery is being initialized, you can add the siren to the wireless system but the siren will
not be ready for normal work until the LED stops flashing.
The battery is to be installed just before installing the siren.
4. Add the siren to the wireless system (see the ABAX 2 / ABAX controller manual).
The sticker with serial number which shall be entered when registering the siren in the
system can be found on the electronics module.
In the INTEGRA / VERSA alarm system, the siren is identified as ASP-100.
Simultaneous operation of the siren by the ABAX 2 and ABAX controller is not
possible.
5. Replace the siren cover.
6. Place the siren in the location intended for its installation.
7. Check the level of signal received from the siren by the ABAX 2 / ABAX controller.
If the signal level is lower than 40%, select another place for installation. Sometimes,
it is sufficient to shift the device ten or twenty centimeters.
The ARF-200 tester makes it possible to check the radio signal strength at the place of
future installation without having to put the siren there.
8. Remove the siren cover.
9. Disconnect the battery from the electronics module.
10. Move aside the catches holding the electronics module and remove it.
11. Place the enclosure base on the wall and mark the location of mounting holes (Fig. 2).
Remember to take into account the mounting hole for tamper protection.
12. Drill the holes for wall plugs (anchors).
13. Use wall plugs (anchors) and screws to secure the enclosure base to the mounting
surface. Remember about the mounting hole for tamper protection. Select appropriate
wall plugs based on the type of the mounting surface (different for concrete or brick wall,
different for plaster wall, etc.).
14. Secure the electronics module in the enclosure base.
15. Connect the battery to the electronics module.
16. Replace the siren cover and fasten it with screws.
17. Configure the siren settings (e.g. the signaling parameters – see the ABAX 2 / ABAX
controller manual).

5 Battery replacement

The new battery must be installed as described below to run the battery
initialization procedure. The required power supply parameters are only
possible with the properly initialized battery.
