Press
Key For 5 Sec.
PRG
To Enter in Parameter Setting
Press
Key
PRG
Press
Key
PRG
Press
Key
PRG
Press
Key
PRG
Press
Key
PRG
Press
Key to Save & Exit
PRG
Password -
R1
(35)
R2
Slave Address -
Range:
R1
1 to 127
R2
Baudrate -
2400,4800
R1
9600,19200
R2
38400 bps
Parity -
R1
None,Even
Odd
R2
R1
Data Type -
Float
R2
Frame Delay
Time -
R1
0 to 100 ms
R2
MODBUS (MFM-142 DC-M1)
Slave Address :
Baudrate :
Parity :
Datatype :
Frame Delay Time :
Read Function Register :
Write Function Register :
Access
Sr.No
Parameter
Type
1
R
kWh Value *
*Note 1 :- In Above Energy Parameter, Energy Value
Representation shown as per below.
Example :- Actual Value = 320126789.321
Above Register Address 1 = 320126789
Below Register Address 2 = 0.321
2
R
DC Voltage
3
R
DC Current
4
R
DC Watt
5
R
Watt/Kilo Watt Status
Selection
Watt
Kilo Watt
6
R
R1 Status
7
R
R2 Status
Note :- To Reset Kwh Enter 15 Value
8
R/W
Reset KWh
9
R/W
Address
10
R/W
Baudrate
Selection
2400
4800
9600
19200
38400
11
R/W
Parity
Selection
None
Even
Odd
12
R
Data Type
Float
13
R/W
Frame Delay Time
14
R/W
Shunt Value
15
R/W
SET Point R1
16
R/W
Delay 1
17
R/W
Relay Fault mode 1
Selection
OFF
ON
18
R/W
Hysterisis 1
19
R/W
SET Point R2
20
R/W
Delay 2
21
Relay Fault mode 2
R/W
Selection
OFF
ON
22
R/W
Hysterisis 2
1 to 127
2400,4800,9600,19200,38400bps
None,Even,Odd
Float
0 to 99 milli sec
0x03 and 0x04
0x06 and 0x10
Register
Data Type
Float
0
N1
2
4
6
8
10
Value
0
1
12
14
16
18
20
Value
0
1
2
3
4
22
Value
0
1
2
24
1
26
28
30
32
34
Value
0
1
36
38
40
42
Value
0
1
44
