- Page 1 INSTRUCTION MANUAL SMWB/E07 Series Wireless Microphone Transmitters and Recorders SMWB/E07 SMDWB/E07 Featuring Digital Hybrid Wireless Technology ® US Patent 7,225,135 Fill in for your records: Serial Number: Purchase Date: Rio Rancho, NM, USA www.lectrosonics.com...
-
Page 2: Table Of Contents
SD Info ........................................13 Restoring Default Settings ..................................13 5-Pin Input Jack Wiring ..................................14 Microphone Cable Terminationfor Non-Lectrosonics Microphones ....................15 Input Jack Wiring for Different Sources .............................16 Compatible Wiring for Both Servo Bias Inputs and Earlier Transmitters: ....................16 Simple Wiring for Servo Bias Inputs ONLY: ............................16 Microphone RF Bypassing ..................................17... - Page 3 Digital Hybrid Wireless Belt-Pack Transmitters ISEDC Notices: Per RSS-210 This device operates on a no-protection no-interference basis. Should the user seek to obtain protection from other radio services operating in the same TV bands, a radio licence is required. Please consult Industry Canada’s document CPC-2-1-28, Optional Licensing for Low-Power Radio Apparatus in the TV Bands, for details.
-
Page 4: Introduction
The input preamp is a unique design that delivers The housing is a rugged, machined aluminum package. audible improvements over conventional transmitter The input jack is a standard Lectrosonics 5-pin type for inputs. Two different microphone wiring schemes are use with electret lavaliere mics, dynamic mics, musi- cal instrument pickups and line level signals. -
Page 5: Features
NOTE: The battery timer feature in many power consumption. The LEDs are intended to simply Lectrosonics receivers is very helpful in measuring catch your attention, not to be an exact indicator of battery runtime. Refer to the receiver instructions remaining time. -
Page 6: Battery Installation
SMWB/E07 Series Battery Installation Long Button Press When the unit is turned off, a long press of the power The transmitter is powered by two AA batteries. We button will start a countdown to turn the unit on with the recommend using lithium for longest life. -
Page 7: Transmitter Operating Instructions
Gain antenna connector is an IR port that can be used to transfer settings from an IR enabled Lectrosonics receiver. Refer to the receiver manual • To stop recording, press MENU/SEL and choose for details. Stop; the word SAVED appears on the screen... -
Page 8: Smwb Main Menu
SMWB/E07 Series SMWB Main Menu From the Main Window press MENU/SEL. Use the UP/Down arrow keys to select the item. Files Use arrow keys to Files Select from 0014A000 select file in list listing BACK 0013A000 Format? Use arrow keys to initiate... -
Page 9: Smwb Power Button Menu
Digital Hybrid Wireless Belt-Pack Transmitters SMWB Power Button Menu From the Main Window press the power button. Use the UP/DOWN arrow keys to select the item. Press SEL to return to Resume the previous screen Press SEL to turn the Pwr Off power off Rf On? -
Page 10: Setup Screen Details
When the frequency step size is set to 25 kHz, the hex number will appear smaller and may include a fraction. Helpful Features on Receivers Fraction To aid in finding clear frequencies, several Lectrosonics b 470 receivers offer a SmartTune feature that scans the tun- 1/4 = .025 MHz... -
Page 11: Record Or Stop
Digital Hybrid Wireless Belt-Pack Transmitters Format 6) If the audio output level of the receiver is too high or low, use only the controls on the receiver to make Formats the microSDHC memory adjustments. Always leave the transmitter gain ad- Files card. -
Page 12: Selecting Frequency Using Two Buttons
100 kHz steps 494.500 to next 100 kHz channel Selecting the Compatibility (Compat) Mode 25 kHz Mode When used with a Lectrosonics Digital Hybrid Wireless ® Freq. 1 block steps receiver, the best audio quality will be achieved with the b 19 system set to the Hybrid compatibility mode. -
Page 13: Selecting Step Size
Choose to name the recorded files by the sequence Normally, the receiver is used to find a clear operat- number or by the clock time. ing frequency. All Lectrosonics Digital Hybrid Wireless ® receivers provide a scanning function to quickly and... -
Page 14: 5-Pin Input Jack Wiring
SMWB/E07 Series 5-Pin Input Jack Wiring Audio input jack wiring: The wiring diagrams included in this section represent the basic wiring necessary for the most common types PIN 1 of microphones and other audio inputs. Some micro- Shield (ground) for positive biased electret lavaliere phones may require extra jumpers or a slight variation microphones. -
Page 15: Microphone Cable Terminationfor Non-Lectrosonics Microphones
VHF transmitters with 5-pin shield jacks require a different termination. Lectrosonics lavaliere microphones are terminated for compatibility with VHF and UHF transmitters, which is different from what is shown here. Rio Rancho, NM... -
Page 16: Input Jack Wiring For Different Sources
Lectrosonics transmitters. Check with the factory Sanken COS-11. to confirm which models can use this wiring. This wiring is fully compatible with 5-pin inputs on Lectrosonics Fig. 11 transmitters such as the LM and UM Series. This is the wiring for the Lectrosonics M152 lavaliere microphone. -
Page 17: Microphone Rf Bypassing
Line Level More Headroom Use 330 pF capacitors. Capacitors are available from (20 dB) Lectrosonics. Please specify the part number for the desired lead style. Leaded capacitors: P/N 15117 Leadless capacitors: P/N SCC330P All Lectrosonics lavaliere mics are already bypassed and do not need any additional capacitors installed for proper operation. -
Page 18: Belt Clips And Pouches
SMWB/E07 Series Belt Clips and Pouches SMWB Single Battery Model SMDWB Dual Battery Model SMWBBCUP SMDWBBCSL Wire clip for Wire clip for dual single battery battery model model; antenna antenna points points UP when UP when unit is unit is worn on a worn on a belt;... -
Page 19: Miscellaneous Accessories
Digital Hybrid Wireless Belt-Pack Transmitters Miscellaneous Accessories SMKITTA5 Mic cable not included TA5 connector kit; with sleeves for small or larger cable; mic cable not included SMSILVER Small vial of silver paste for use on battery door retaining knob threads 55010 MicroSDHC memory card with... -
Page 20: Lectrorm
Each version also has a remote control activation. mechanism to prevent accidental activation of the tone. Please be aware this app is not a Lectrosonics product. It is privately owned and operated by New Endian LLC, www.newendian.com. -
Page 21: Silver Paste On Sm Series Transmitter Thumbscrews
Digital Hybrid Wireless Belt-Pack Transmitters Silver Paste on SM Series Transmitter Thumbscrews Silver paste is applied to thumbscrew threads on new Simply hold the cloth around the threads and turn the units at the factory to improve the electrical connection thumbscrew. -
Page 22: Firmware Update
SMWB/E07 Series Firmware Update Firmware updates are made using a microSDHC 7) If you re-insert the update card and turn the power memory card. Download and copy the following firm- back on for normal use, the LCD will display a mes- ware update files to a drive on your computer. -
Page 23: Recovery Process
Digital Hybrid Wireless Belt-Pack Transmitters Recovery Process In the event of a battery failure while the unit is re- cording, a recovery process is available to restore the recording in proper format. When a new battery is installed and the unit is turned back on, the recorder will detect the missing data and prompt you to run the recovery process. -
Page 24: Specifications
SMWB/E07 Series Specifications Transmitter Recorder Operating frequencies: Band A1: 470.100 - 537.575 Storage media: microSDHC memory card Band B1: 537.600 - 607.975 File format: .wav files (BWF) Channel Spacing: Selectable; 25 or 100 kHz A/D converter: 24-bit RF Power output: Switchable;... -
Page 25: Troubleshooting
Digital Hybrid Wireless Belt-Pack Transmitters Troubleshooting It is important that you follow these steps in the sequence listed. Symptom: Possible Cause: Transmitter Battery LED off 1. Batteries are inserted incorrectly. when Power Switch “ON” 2. Batteries are low or dead. No Transmitter Modulation LEDs 1. -
Page 26: Service And Repair
LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest flat rate plus parts and shipping. - Page 27 Digital Hybrid Wireless Belt-Pack Transmitters Rio Rancho, NM...
- Page 28 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
