Q
uick
S
tart
G
uide
L-Series
Wireless
Microphone
System
LR Receiver
LMb Transmitter
LT Transmitter
Fill in for your records:
Serial Number:
Purchase Date:
Digital Hybrid Wireless
U.S. Patent 7,225,135
Technology
®
This guide is intended to assist with
initial setup and operation of your
Lectrosonics product.
For a detailed user manual, down-
load the most current
version at:
www.lectrosonics.com
26 Mar 2015
Advertisement
Table of Contents
Related Manuals for Lectrosonics L series
Summary of Contents for Lectrosonics L series
- Page 1 ® U.S. Patent 7,225,135 This guide is intended to assist with initial setup and operation of your Fill in for your records: Lectrosonics product. Serial Number: For a detailed user manual, down- load the most current version at: Purchase Date: www.lectrosonics.com...
-
Page 2: Controls And Features
Controls and Features 614.4 - 691.1 MHz FCCID:DBZLMBC1 S/N XXXXX Lectrosonics, Inc. Model: LMBC1 Made in U.S.A. IC: 8024A-LMBC1 PORT 623.400 PWR/FUNC AUDIO 623.400 LECTROSONICS, INC. - Page 3 Frequency block XXX (XXX.X - XXX.X MHz) This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. CAN RSS-Gen/CNR-Gen Battery Doors LT and LR models LMb model www.lectrosonics.com...
-
Page 4: Keypad And Lcd Interface
Menu setup items are arranged in a vertical list on the LCD. Press MENU/SEL to enter the menu, then navigate with the UP and DOWN arrows to highlight the desired setup item. Press MENU/SEL to enter the setup screen for that item. LECTROSONICS, INC. - Page 5 LCD backlight duration 5 Minutes LCD Mode Use arrow keys to select Wht on Blk LCD Mode BACK Blk on Wht LCD backlight mode Retore Factory Use arrow keys to accept or reject Default default settings BACK restoration of default settings www.lectrosonics.com...
-
Page 6: System Setup Procedures
Mode 7* Mode 7 Mode 6* Mode 6 IFB Series NA Dig. Hybrid is the best mode to use when both transmitter and receiver are Digital Hybrid Wireless models. This compandor-free, wide deviation mode produces the best audio quality. LECTROSONICS, INC. - Page 7 Mode 3 is a special compatibility mode for use with another brand of wireless. Contact the factory for details. 200 Series works with legacy Lectrosonics models such as all UM200, UH200 and UT200 Series transmitters. 100 Series works with Lectrosonics UM100 transmitters.
- Page 8 IR ports facing one another within two feet or so apart and press the UP arrow button to complete the procedure. If you are not using a Lectrosonics transmitter with an IR port, simply return to the Main Window and observe the frequency that was chosen by Smart Tune.
- Page 9 If you have not already set the frequency on the transmitter in the previous procedures, use IR Sync or complete the settings manually. Lectrosonics transmitters with IR Sync: On the LR receiver, navigate to IR Sync on the menu and press the MENU/ SEL button.
- Page 10 Other Transmitters: Earlier Lectrosonics transmitters provided LEDs to accurately indicate full modulation, with continuously variable gain controls for a precise adjustment. The LEDs operate in the same manner as those shown here for the L-Series transmitters.
- Page 11 Some transmitters from brands other than Lectrosonics can also be used if the appropriate compatibility mode set is set in the receiver. Observe the audio level meter on the LR receiver LCD as you adjust the input gain on the transmitter to see the modulation level.
-
Page 12: Limited One-Year Warranty
This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
