Page 1: Handheld Transmitter
INSTRUCTION MANUAL HH/E01 Handheld Transmitter Digital Hybrid Wireless Technology ® US Patent 7.225.135 Fill in for your records: Serial Number: Purchase Date: Rio Rancho, NM, USA www.lectrosonics.com... - Page 2 HH/E01 LECTROSONICS, INC.
-
Page 3: Table Of Contents
Hand Held Transmitter Table of Contents General Technical Description ..........4 Capsule and Battery Installation .......... 6 Control Panel ................. 7 Powering On ................7 Powering Off ................7 Standby Mode ................ 7 Battery Condition ..............8 Navigating Menus and Screens ........... 8 About Setting Audio Gain ........... -
Page 4: General Technical Description
HH/E01 General Technical Description Introduction Digital Hybrid Technology The HH/E01 handheld transmitter uses state-of- All wireless links suffer from channel noise to some the-art Digital Hybrid Wireless wireless technology, degree and all wireless microphone systems seek ® selectable output power and a versatile microphone... - Page 5 IR Sync to operate and remain stable with full power output down to low battery voltages. The HH/E01 is equipped with an IR (infrared) port for use with receivers that will be developed in the Menu-Driven Control future. Settings such as frequency stored in the receiver will be sent to the transmitter via the IR port.
-
Page 6: Capsule And Battery Installation
HH/E01 Capsule and Battery Installation A common threaded mount allows the use of a va- The control panel and battery compartment are riety of different capsules from different manufactur- accessed by opening the lower housing. Rotate the ers. Capsules are attached with a right-hand thread. -
Page 7: Control Panel
Hand Held Transmitter Control Panel Powering Off Six membrane switches on the control panel are Press and hold the Power Button for several seconds used to set up the transmitter by navigating the and observe the countdown on the LCD. The count- menus on the LCD and selecting the desired values. -
Page 8: Battery Condition
Rechargeable batteries give little or no warning Rolloff when nearing depletion. If you use rechargeable batteries in the HH/E01, we recommend trying fully charged batteries first, noting the length of time that IMPORTANT: See the section About Setting the batteries will run the unit, and in the future using Audio Gain on page 10 for details. - Page 9 Hand Held Transmitter Compat Rf On? The HH/E01 can be used with Lectrosonics Euro The transmitter output can be switched on or off with version IFB systems by selecting the correct Com- this menu item. This is useful, for example, when the patibility Mode.
-
Page 10: About Setting Audio Gain
HH/E01 Mute and Talkback About Setting Audio Gain Functions The two bicolor Modulation LEDs (located at the bot- A special button (the Side Button) on the outside of tom of the control panel) provide a visual indication the housing can be configured to provide a mute or of the audio signal level entering the transmitter. - Page 11 Hand Held Transmitter Main Window Displays for Mute and Talkback Functions The function of the Side Button is displayed in the LCD Main Window. MUTE 623.400 623.400 623.400 No Function Talkback Audio Mute When the Side Button is pressed, the function will be active and the LCD will display an indication.
-
Page 12: Troubleshooting
4) HH/E01 Frequency setting is not correct. 5) Compatibility Mode mismatch between transmitter and receiver. HISS AND NOISE -- AUDIBLE DROPOUTS 1) HH/E01 Audio Gain set too low. See page 10 for proper audio gain setting. 2) Receiver antenna missing, defective or obstructed. -
Page 13: Specifications
(Normal Tuning mode); 256 frequencies in 100 kHz steps (Fine Tuning mode) 1024 frequencies in 25 kHz steps (except block 23 and 33 - contact Lectrosonics for details) Channel Step Size: Normal Tuning mode: 100 kHz in Normal Tuning mode... -
Page 14: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In-warranty re- pairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest flat rate plus parts and shipping. - Page 15 Hand Held Transmitter Rio Rancho, NM...
- Page 16 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
