Page 1: Gas Cooktop
I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS COOKTOP S e rie s G512 G514 G515 G516 G518 For use in GB, IE &... - Page 2 800 263 1455 (Toll Free) NEW ZEALAND Moffat Limited Web: www.moffat.co.nz E.Mail: sales@moffat.co.nz Main Office: (tel): 0800 663328 UNITED KINGDOM Blue Seal Web: www.blue-seal.co.uk E.Mail: sales@blue-seal.co.uk Sales: (tel): +44 121 327 5575 (fax): +44 121 327 9711 Spares: (tel): +44 121 322 6640...
-
Page 3: Table Of Contents
Contents Blue Seal Gas Cooktops G512 Gas Cooktop 300mm wide. G514 Gas Cooktop 600mm wide. G515 Gas Cooktop 750mm wide. G516 Gas Cooktop 900mm wide. G518 Gas Cooktop 1200mm wide. Introduction ....................2 Specifications .................... 3 Model Numbers Covered in this Specification... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your BLUE SEAL COOKTOP, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new BLUE SEAL COOKTOP, there are two important things you can do. -
Page 5: Specifications
Griddle options with 4 models of base unit available (except G512 Model). Fitted with either 'Individual Flame Failure' (F) or 'Pilot and Flame Failure' (PF) option for each open burner. Griddles are fitted with... -
Page 6: Gas Supply Requirements
Specifications Gas Supply Requirements - Australia Natural Gas LP Gas (Propane) Input Rate (N.H.G.C.) 28 MJ/hr 28 MJ/hr - each Open Burner - each 300mm Griddle Section 21 MJ/hr 21 MJ/hr 1.13 - 3.40 kPa 2.75 - 4.50 kPa Supply Pressure Burner Operating Pressure (*) 0.95 kPa 2.6 kPa... -
Page 7: Gas Connection
Specifications - All Other Markets Natural Gas Town Gas (**) Input Rate (N.H.G.C.) 28 MJ/hr 28 MJ/hr - each Open Burner - each 300mm Griddle Section 21 MJ/hr 21 MJ/hr 1.13 - 3.40 kPa 0.75 - 1.50 kPa Supply Pressure Burner Operating Pressure (*) 0.95 kPa 0.63 kPa... -
Page 8: Dimensions
Dimensions Dimensions for Bench Models G512-B = Rating Plate Location for this option. G514-B G516-B G518-B Refer to Page 9 for Cooktop Options... - Page 9 Dimensions Dimensions for Cabinet Base Models G512 models - not available in Cabinet Base option. = Rating Plate Location for G514-CB this option. G516-CB G518-CB Refer to Page 9 for Cooktop Options...
- Page 10 Dimensions Dimensions for Leg Stand Models G512 models - not available in Leg Stand Base option. = Rating Plate Location for G514-LS this option. G516-LS G518-LS Refer to Page 9 for Cooktop Options...
- Page 11 Dimensions Dimensions for Refrigerated Base Models G512 and G514 models - not available in Refrigerated Base option. G516-RB = Rating Plate Location for this option. G518-RB Refer to Page 9 for Cooktop Options...
- Page 12 G518-A G516-A NOTE: G512 models are only available in Bench Model (-B) option. G514 models are available in Bench Model (-B), Cabinet Base (-CB), or Leg Stand (-LS) model options. G516 and G518 models are available in Bench Model (-B), Cabinet Base (-CB), Leg Stand (-LS), or Refrigeration Base (-RB) model options.
-
Page 13: Installation
Blue Seal Cooktops are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering gas and fire safety. -
Page 14: Clearances
Installation Clearances NOTE: Only non-combustible materials can be used in close proximity to this appliance. Combustible Surface Non Combustible Surface Left / Right hand side 250mm (*) Rear 50mm Side clearances can be 50mm when adjacent surface is at least 100mm below cooking surface. Assembly NOTE: ... -
Page 15: Gas Connection
NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED PERSON. Blue Seal Cooktops do not require electrical connection, as they function totally on the gas supply. It is essential that gas supply is correct for Cooktop being installed and that adequate supply pressure and volume are available. -
Page 16: Commissioning
Installation Commissioning Before leaving the new installation; Check the following functions in accordance with operating instructions specified in ‘Operation’ section of this manual. Lighting the Griddle. Light the Open Burners. (F - Option). Light the Open Burners. (PF - Option). ... -
Page 17: Operation
/ operator. Blue Seal appliances have been designed to provide simplicity of operation and 100% safety protection. Improper operation is almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product. -
Page 18: Open Burners ('F' - Flame Failure Option)
Operation Open Burners ('F' - Flame Failure Option) Lighting the Open Burners Flame Failure Protection is incorporated for each burner by way of a thermo-electric system which will shut off gas supply to that burner in the event that burner goes out, so that un-burnt gas is not expelled. -
Page 19: Griddle
Operation Griddle Lighting the Griddle a. Depress gas control knob and rotate anti-clockwise to ‘PILOT’ position. b. Hold gas control knob depressed, press piezo ignition button to ignite pilot burner. Repeat Items 1 to 2 until pilot is lit. c. Release gas control knob approximately 10-20 seconds after lighting pilot. d. -
Page 20: Cleaning And Maintenance
Cleaning and Maintenance Before Commencing Cleaning Caution Always turn off the gas / electrical supply before cleaning the appliance. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. NOTE: ... -
Page 21: Open Burner Cleaning
Cleaning and Maintenance Open Burner Cleaning Griddle Plate Cleaning 1. Remove pot stands, burner caps, burner bowls It is recommended that a flat blade scraper is used to clean the griddle surface, these are not supplied and pot stand supports from top of cooktop. Wash with hot soapy water, using a soft with griddle but may be purchased separately. -
Page 22: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during operation of your equipment. This fault finding guide is intended to help you accurately diagnose and correct problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 23: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure Caution Ensure that the Appliance is isolated from the gas supply before commencing servicing. NOTE: These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. ... -
Page 24: Gas Specifications
Gas Conversion and Specifications Griddle Piezo Igniter Pilot Supply Tube Carry out the following:- Remove griddle plate section and heat shield. Remove main burner. Disconnect piezo igniter from mounting Pilot Burner bracket. (For access purposes). Disconnect pilot supply tube from pilot Main Burner Injector burner to access pilot injector. -
Page 25: Gas Regulator
Gas Conversion and Specifications Gas Regulator NOTE, Pin rotated - NAT Gas / LPG / Butane Only. for Natural Gas NOTE: The gas regulator supplied is convertible between Natural Gas and LP Gas, but it’s outlet NOTE, Pin rotated for LPG pressure is fixed ex-factory and is NOT to be adjusted. -
Page 26: Gas Specifications
Gas Conversion and Specifications Gas Specifications - Australia Natural. Gas LP Gas (Propane) Main Burner Ø 2.45mm Ø 1.50mm Open Burner Pilot Burner ('PF' Models Only) 0.30 0.20 Main Burner Ø 2.10mm Ø 1.30mm Pilot Burner 0.35 0.23 Griddle Burner Aeration Setting Fully open Fully open Supply Pressure... - Page 27 Gas Conversion and Specifications - All Other Markets Natural Gas Town Gas (**) Main Burner Ø 2.45mm Ø 4.50mm Open Burner Pilot Burner ('PF' Models only) 0.30 0.60 Main Burner Ø 2.10mm Ø 3.40mm Griddle Pilot Burner 0.35 0.60 Burner Aeration Setting Fully open Fully open Supply Pressure...
-
Page 28: Replacement Parts List
Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. further information servicing instructions, contact your nearest authorized service branch (contact details are as shown on the reverse of the... - Page 29 Replacement Parts List General 227014 Pot Stand. 230286 Spill Tray (G512 Series). 230277 Spill Tray (G514 / G518 Series). 230273 Spill Tray (G516 Series). 227855 Adjustable Legs (84mm - Bench Models). 227850 Adjustable Legs (Flush Stud) (150mm - CB / RB Models).
