5.10 Machine configuration menu
Basic machine settings are defined in the machine configuration menu.

5.10.1 Selecting, changing and saving parameters

A
B
B
B
B
B
B
B
B
B
B
B
B
Display
54
A
A A
B B B
B
B B B
B
B B B
B B
B
B
B
B
B
Setting/selection
Exit the menu
Exit
Switching the machine off and on
Required for applying various configuration parameters
Power source menu
Switch ignition mode
------- HF ignition
------- Liftarc
HF intensity
------- Standard: Maximum value for the high-voltage ignition pulse Up
------- Reduced: Reduced value for the high-voltage ignition pulse Up
Re-ignition after arc interruption > see 5.1.6.3 chapter
------- JOB-dependent time (ex works 5 s).
------- Function disabled or numerical value 0.1–5.0 s.
