ENSIM SENSORS ELS Manual page 8

2.8. Electrical Installation
Make the electrical connection of the instrument according to details on its label, table and cable figures in this manual
B10p, B10x , B101x Housing
Two pieces independent contact
NO or NC
Bottom
Contact
Top
Contact
Note: RLY LED has been designed
to turn off the pump is running.
ISO 4400 (DIN 43650A)
2
3
1
Single Contact
NO
ML-2 Military Type
(CA3101A)
25
A B
Two pieces double contact
NO / NC (SPDT)
Liquid Level Contact
(12 / 24 VDC)
Rly Pwr
S
Supply
NC NO
Com
Socket P01 , P03 , P04
Single Contact
NO / NC (SPDT)
Single Contact
NO
NC NO
Bottom
Contact
NC NO
Top
Contact
Com
2
3
1
Four Contacts
NO
8
Four pieces contact
NO or NC
1
B035, P52, P65
Housing
1 2 3 4 5
2
3
1
Two pieces single contact
NO
ML-5 Military Type
30.5
A
E B
D C
2
3
4
Com
A: 1 Contact
B: 2 Contact
C: 3 Contact
D: 4 Contact
E: Common
