ENSIM SENSORS ELS Manual page 13

2.10. Order Form :
Order Form : Please consider sample models when coding
1
MODEL
Standart Version ......................................ELS
ELSy (For Yacht Industry).......................ELSy
2
CERTIFICATE
None.....................................................................0
3
HOUSING
2 2
None..............................................................0000
Plastic Housing , B10p
Plastic Housing , B11p
Plastic Housing , B20p
Plastic Housing , B037
Aluminium Housing , B10x
Aluminium Housing , B20x
Aluminium Housing , B22x
4
ELECTRICAL CONNECTION
Terminal (For Housing Models)........................00
Polyamide Large Socket P01 ......................... 50
Polyamide Small Socket P02 ......................... 51
Polyamide Large Lighted Socket P03 ............ 52
Military Socket ML-2, 2 Pins ........................... 60
Military Socket ML-5, 5 Pins ........................... 61
5
CONNECTION
With Pipe- Without Thread........................0000
Thread 1/8”BSP.........................................0001
Thread 1/4”BSP.........................................0002
Thread 3/8” BSP.......................................0003
Thread 1/2” BSP.......................................0004
Thread 3/4” BSP.......................................0005
Thread 1” BSP...........................................0006
Thread 1 1/4” BSP.....................................0008
Thread 1 1/2” BSP.....................................0009
Thread 2” BSP...........................................0012
Thread 1/2” BSP (Moving Type)...............0112
Thread M10x1 Straight Type....................0113
Thread 1/8” BSP Elbow Type...................0111
Thread M10 x 1 Elbow Type....................0400
Thread 3/8” BSP Elbow Type...................0109
Thread 1/2” BSP Elbow Type ..................0110
............................5239
.............................5310
.............................5046
.............................5023
.......................5109
.......................5150
.......................5308
ELSp (For Hydraulic Tanks)...............................ELSp
ELSm (For Machinery Manufacturing)..............ELSm
(EN10204-3-1) Material Certification...........................1
Stainless Steel Housing , B101x..........................5265
PC Grey , P52......................................................5062
PC Grey , P65......................................................5294
Special........................................................................x
M12- 2 Pins....................................................................70
M12- 5 Pins....................................................................71
M12- 8 Pins...................................................................72
PVC Cable (Max .60 °C)...............................................80
PVC Cable (Max. 105 °C).............................................81
Silicon Cable (Max. 200 °C)..........................................82
PTFE Cable (Max. 230 °C)...........................................83
Steel Shielded Cable (Max. 350 °C).............................48
Special Cable..................................................................x
Special Socket............................................................x
1/8” NPT...................................................................0200
1/4” NPT......................................................................0201
3/8” NPT...............................................................0202
1/2” NPT...............................................................0203
3/4” NPT...............................................................0204
1” NPT.............................................................0205
1 1/4” NPT............................................................0206
1 1/2” NPT............................................................0207
2” NPT............................................................0208
DN 25 - PN16 Flanged..................................................0502
DN 32 - PN16 Flanged.................................................0503
DN 50 - PN16 Flanged.................................................0505
DN 80 - PN16 Flanged................................................0507
DN 100 - PN16 Flanged...................................................0508
Ø56 Special Flange..............................................1458
Special........................................................................x
Note: Refer to the table for others.
13
