3. Failure Delection
Breakdown
Fluid is leaking
It does not contact
or it contacts
continuously
Body was broken
Unsteady operation
in the contact
If you find an error, try to eliminate it by using this table or send the instrument to our service address for repair.
The instrument should be repaired only by authorized service!

4. Disassembly of Instrument

Instrument should be disassembled while feeding and pressure is not available!

5. Service

The instrument does not require maintenance. If it is desired, residue accumulated inside should be blown according to kind
of fluid and instrument can be cleaned with soft cleaning solutions. Measures should be taken during the disassembly.

6. Recalibration

Calibration is not required during long period useful life of a level switch.
7. Repair – Manufacturer Address
If irreparable breakdowns occur, the instrument should be sent to us for repair purpose. Before this, the instrument should be
cleaned carefully and packaged so as not to be broken. Furthermore, you should also add a detailed explanation which
describes the breakdown while instrument is sent. If your instrument contacts with harmful substances, decontamination
report should be also sent additionally. In the event that instrument does not have any decontamination report or our service
department has doubts about instrument, repair process will not start until an acceptable report is sent.
If the instrument contacts with hazardous substances, necessary measures should be taken for decontamination!
Service -Manufacturer Company Name and Address:
LONCA MAK. SAN. TÝC. A.Þ.Ferhatpaþa Mahallesi Gazipaþa Caddesi No:104 A 34888 Ataþehir / ÝSTANBUL - TÜRKÝYE
Tel:+90 216 505 05 55 Faks:+90 216 515 45 84 E-Mail: lonca@ensim.com.tr Web: www.ensim.com.tr

8. Disposal

The instrument should be disposed according to 2002/96/EC and 2003/108/EC European Directives (waste electrical and
electronic instruments). Waste electrical and electronic equipment should not be mixed with domestic wastes!
If the instrument has contacted with harmful substances, special attention should be paid for its disposal!

9. Terms of Warranty

The instrument has warranty legally for 24 months after delivery date. Warranty demands are not accepted in case of
inappropriate operation, damage on the instrument or any modification on the instrument.
10. Terms of Return
In the return of materials, user should send an open list related to damage or problem, malfunction of the material
to be returned or its operation in the different modification, with the instrument. If it is required to return the
material, used in the dangerous, corrosive or toxic fluid, in this case, used part should be cleaned very carefully.
Security of personnel should be ensured. All products to be returned should be sent to our company address, which
we have stated.
Probable cause
There is a hole on the body.
-Socket connection is not touched.
-Product was exposed to the magnetic field
in the ambient.
-Connetion angle is not corrrect.
-Contact may have been burned.
-Tightening the screws more than adequate during
the assembly.
-Product falling or taking a blow from outside.
-Product was exposed to the magnetic field in the ambient.
-Product was exposed to vibration.
-Product was exposed to high temperature.
Failure detection\correction
-Check that is worked under appropriate condition
and then contact with producer company.
-Check for socket connections.
-The factor which constitutes the magnetic field
should be removed or insulated.
-Correct assembly angle.
-Inform authorized service.
-Inform authorized service.
-The factor which constitutes the magnetic fieldshould
be removed or insulated.
-Vibration which will effect the product should
be prevented or it should be attached to any place
without vibration.
-Use in the appropriate opearating temperature.
