ENSIM SENSORS ELS Manual page 3

1.4.Technical Specifications :
MODEL
Float Material
Wetted Parts Material
Pipe Material
Float Type
Working Temperature
Mechanical Connection
Electrical Connection
Number of Float
Stem Lenght
Number of Contact
Contact Current
Max.Contact Capacity
Max. Supply Voltage
MODEL
Float Material
Wetted Parts Material
Pipe Material
Float Type
Working Temperature
Mechanical Connection
Electrical Connection
Number of Float
Stem Lenght
Number of Contact
Contact Current
Max.Contact Capacity
Max. Supply Voltage
Test Rod:
Rod Material 304 Stainless Steel (Std.) Opt. 316 Stainless Steel
304 Stainless Steel (Std.) Opt. 316 Stainless Steel
Arm Material
It has been manufactured as spring-operated. Optionally, the handle can be put
inside the housing.
Level Control Device :
Power Supply
Output
Working Temperature
Dimension
Input
ELS
304 Stainless Steel
304 Stainless Steel (Std.) Opt. 316 St.St.
304 Stainless Steel (Std.) Opt. 316 St.St.
S4A or S40A (Std.) Selectable from Table.
Max. 125 °C
2" BSP (Std.) Opt. Selectable
Terminal, With Cable, With Socket
1 (Std.) Available Numerous
Max. 2500 mm
(Thread Included)
2 x SPST - NO (Std.) Opt. can be added
1,5 Amper (Std.)
50 W / VA
200 VDC / 250 VAC (Std.) Opt. Selectable
ELSp
PU (Std.)
Aluminium (Std.) Opt. PVC, Delrin, PTFE, PFT
Brass (Std.) Opt. PVC
P3 (Std.) Selectable from Table.
Max. 80 °C
1" BSP + Nut
Terminal, With Cable, With Socket
1 (Std.) Available Numerous
Max. 2500 mm
(Thread Included)
2 x SPST - NO (Std.) Opt. can be added
1,5 Amper (Std.)
50 W / VA
200 VDC / 250 VAC (Std.) Opt. Selectable
220 VAC , 2.8 VA
2 pcs. 5A / 250 VAC Relay (Start/Stop)
(-) 20 °C...(+) 70 °C
72 mm x 72 mm
Contact information , coming from ELS
ELSy
PU (Std.)
304 Stainless Steel (Std.) Opt. 316 St.St.
304 Stainless Steel (Std.) Opt. 316 St.St.
P3 (Std.) Selectable from Table.
Max. 80 °C
1 1/4" BSP
Terminal, With Cable, With Socket
1 (Std.) Available Numerous
Max. 2500 mm
(Thread Included)
2 x SPST - NO (Std.) Opt. can be added
1,5 Amper (Std.)
50 W / VA
200 VDC / 250 VAC (Std.) Opt. Selectable
ELSm
304 Stainless Steel (Std.) Opt. 316 St.St.
304 Stainless Steel (Std.) Opt. 316 St.St.
304 Stainless Steel (Std.) Opt. 316 St.St.
S1Y (Std.) , Selectable from Table.
Max. 125 °C
1/8" BSP + Nut (Std.) Opt. M10 x 1 mm² + Nut
With Cable,
1 (Std.) Available Numerous
Max. 2500 mm
(HEX Included)
2 x SPST - NO (Std.) Opt. can be added
1 Amper (Std.)
10 W / VA
200 VDC / 140 VAC (Std.) Opt. Selectable
SK P1 / SK P2
3
Protection Case :
l : 304 Stainless Steel
Materia
Welded manufacturing
Opens - Closes Hinged
To Protect Against external conditions.
