Cal 2 Calibration - Mercury SmartCraft Systems Monitor Operation Manual

CAL2 Display Calibrations:
•Paddle Wheel Speed Sensor Frequency Setting
•Pitot Water Pressure Speed Sensor Input Setting
•Pitot Water Pressure Speed Sensor Multiplier
•Fuel Tank Calibration
1. Turn ignition key to the on position.
2. Press and hold
CAL 1 calibration screen. Press and hold
for 3 seconds to bring up the CAL 2 calibration screen.
NOTE:Press and hold
the CAL 2 calibration screen.
Press the
1. Press the
0 =No Pitot pressure sensor
1 = 100 PSI
2 = 200 PSI
2. Press the

CAL 2 CALIBRATION

and
button to move to the next calibration screen.
button to select.
button to move to the next function.
for 3 seconds to bring up the
and for 3 seconds to get out of
Cal 2 Start Screen
Pitot Water Pressure
Sensor Input
Select the pressure input of the
Pitot water pressure sensor on
the engine.
NOTE:The standard speed in-
put on production Mercury Out-
boards is 100 PSI. Certain High
Performance applications may
require a 200 PSI input.
20
and again
