SnapCOM Prime 4G
* ALWAYS TEST THE UNIT ON SITE BEFORE

Wiring Connections

To Earth
Rod!
24V DC IN
(PSU included)
Must use a 45 Watt solar panel (minimum)
and at least a 30Amp Hour battery (or two
15Amp Hour batteries for 24V solar.
ALTERNATIVE WIRING EXAMPLE
Relay
LOCK POWER
SUPPLIES
ARE NOT
INCLUDED AS
2
PART OF THE
KIT.
- MMS Advanced GSM Intercom
INSTALLATION TO AVOID RE-STOCKING FEE *
Tip: All main connections are pre-wired. Below are
optional wiring additions for 3
SOLID RED
SOLID RED
SOLID RED
Note:
DC Outputs **SD card not included.**
DETECT
Gate Position
Limit switch
(optional)
101
Relay
2
Relay
OPEN
1
Exit Button
(optional)
Optional
Keypad or
Prox
Tip: See the full manual for more
Keypad
detail on auxiliary connections
PWR | COMMs
PROX PCB
1 2 3
SLAV E IN
SLAVE SLAVE CONNECTIONS
CONNECTIONS (Optional. Check website for instructions)
SLAV E OUT
1 2 3
COI L
ALTERNATIVE WIRING EXAMPLE
Relay
STRIKE
LOCK
SECONDARY
These diagrams are provided for
guidance only. Please refer to the lock
wiring instructions before connecting.
See full T&C's on our website
rd party controllers.
PCB Status LEDs
= PCB POWERED ON
+BLUE FLASHING = SEARCHING
+ BLUE FLASHING + GREEN FLASHING = SUCCESSFULLY CONNECTED
Power off unit to remove or insert SD card.
SPK MIC BTN
USB-B
Micro
Port
SD Card
Modem
SIM
Tray
Camera
Check with your network provider for the correct APN for 4G data.
Once you have confirmed the APN enter it in place of 'APNinfo' in an SMS to the intercom.
Prox and Keypad units are
optional extra's.
Up to 5 additional auxiliary
Prox or Keypad units can be
Ensure the PCB is powered on and connected
added to a single GSM PCB.
to the network with a GREEN flashing LED.
This will provide a
Then send the below text as an SMS to the
maximum of 8 separate
intercom Sim number. A power reboot is
relays to control.
required after the 'OK' reply message is
received back.
MAGNETIC LOCK
Passcode
SIM ORIENTATION
ALWAYS ensure the system is switched
OFF when adding or removing your
SIM card and ensure the orientation is
correct.

CONNECTION TO NETWORK

Quick Flashing = Standby | Constant ON/OFF =
CHANGE APN (for VoLTE / 4G services and MMS)
The system will be pre-programmed with the APN for the
use a different network then the correct APN must be set for full operation.
via SMS
(if connected to network) Contact Technical Support or check our resources page for
1. Power off the unit, then press and hold the call button
and power the unit on again.
2. Upon power up, a long tone will be emitted from the
speaker and the blue LED will remain solid - it is now in
the APN setting mode.
9999#97APNinfo#
3. After this, enter the APN serial number through the
keypad then press #. (e.g. if you want to set APN No. 18,
press 1 - 8, then #. A long beep will again be heard).
APN info for
Command
4. Reboot unit.
SIM network
(add APN)
** Setting the APN will autofill the relevant MMS settings required for the
intercom to function properly, assuming the APN is present on the whitelist.
If the APN is not on the whitelist, the MMS details will need programmed
separately (see SMS strings on page 3).
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALUS.COM
MODEM LED
INDICATOR
Searching
Tracfone
network. If you wish to
via Keypad (if no 3G signal)
a list of the APN serial numbers.
Search for
'APN Flyer – SNAPCOM'
