Homeowner User Manual
For Service, Warranty and Support Contact:
Install Company Name:
Installer Phone Number:
Installer Email Address:
Date of Install:
Note: For legal and safety reasons, the manufacturer cannot offer telephone
technical support to un-certified or non-qualified persons. Technical support
can only be delivered via a qualified gate-safe installer.
P a g e
| 1
Advanced GSM Intercom System
Installed By:
For
Advertisement
Table of Contents
Related Manuals for AES Cellcom Prime6
Summary of Contents for AES Cellcom Prime6
- Page 1 Homeowner User Manual Advanced GSM Intercom System For Service, Warranty and Support Contact: Installed By: Install Company Name: Installer Phone Number: Installer Email Address: Date of Install: Note: For legal and safety reasons, the manufacturer cannot offer telephone technical support to un-certified or non-qualified persons. Technical support can only be delivered via a qualified gate-safe installer.
-
Page 2: Table Of Contents
Contents …………….Pg 3 Overview of System …………….Pg 3 Receiving a call and opening gates / door …………….Pg 3 Access control by caller ID (CLIP) …………….Pg 4 Using the APP …………….Pg 5 Summary of APP home screen …………….Pg 6 Opening gate by APP …………….Pg 6 Adding Keypad Codes …………….Pg 7... -
Page 3: Overview Of System
Overview of System Thank you for purchasing an AES Intercom system. This product is a GSM Intercom system, which operates on GSM phone networks. You will need to ensure you have adequate cellular coverage at your location before using this product. - Page 4 Using the Cellcom Prime App You can use the free Cellcom Prime app on Android phones and iphones. Look for the for the icon below or scan the QR code.. 2. Select your intercom type 2G/3G or 4G (this changes how the Proximity part works) 1.
-
Page 5: Summary Of App Home Screen
Summary of the App Home Screen Switch between output 1 and 2 Speed dial gates to open Unlatch (allow held open gates Latch (hold open to close). This gates). This will will send SMS send SMS string string to the to the intercom. -
Page 6: Opening Gate By App
Opening the gate by App Press the main button as shown. On Android phones it will automatically call the intercom and trigger the gate/door. For iphones, it will take you to your dialling screen with the number pre-loaded and you can press to dial (this is a security feature by apple). - Page 7 Permanent Codes (2G or 3G device) Add a new code (up to 4 digits) Enter 1 for the main output relay, or 2 for the secondary output (ask your installer if this is being used) Can be 1 to 9999 seconds (2.7 hours). For Automatic Gates Enter 0 for a latching code (hold open).
-
Page 8: Auto Expiring Codes
Auto-Expiring Temporary Codes Up to 30 codes can be entered along with an auto expiry time in hours, from 1 hour to 168 hours (1 week). Once the time has expired, the keypad code will automatically be deleted from the memory. Add a new code (up to 4 digits) Enter the expiry time in hours (1-168) Press Save to send SMS (iphone users must... -
Page 9: Permanent 24/7 Cards
Permanent 24/7 cards/tags Add a new card (enter all 10 digits) Enter 1 for the main output relay, or 2 for the secondary output (ask your installer if this is being used) Can be 1 to 9999 seconds (2.7 hours). For Automatic Gates Enter 0 for a latching code (hold open). -
Page 10: Time Restricted Cards
Time Restricted Prox Cards Up to 20 cards can be added which will only operate during pre-set times and days of the week. This is useful to improve security by restricting access to certain times. Add a new card (enter 10 digit serial number) Select the days during which the card should work, and between which times. - Page 11 Time Clock opening and closing of gates timeclock/automatic/autoclosing Note: There are 2 main ways your installer can set up gate automation. 1: Automatic closing – this is when you typically open your gates via intercom or fob, and they close automatically again after a pre-set time delay. If your gates operate in this way, then you can use this screen to control them to open and close at pre-set times of the day and week.
-
Page 12: Status Options
Status Options (Press Clock button, then Status) These buttons are useful to manage your intercom, visitors, access, and the current status of the gates for example. Can be used to check if the intercom reception is ok. You will receive a SMS reply with a signal level on a scale of 1-31 Check stored phone numbers for dial out and CallerID access. - Page 13 Stored Keypad Codes This button will send an SMS string to the intercom to check the keypad codes which are stored in the unit. NORM = Normal codes, can be used 24/7. TEMP = Temporary codes which will auto expire. PLAN = Time restricted codes.
-
Page 14: 24/7 Callerid Access
24/7 Caller ID access (Settings button/caller ID) This intercom can store up to 100 visitor phone numbers which can call the intercom at any time. The intercom will recognise their incoming number, hang up, and grant access in a free call. Enter up to 4 phone numbers at a time, and press SAVE to send the programming SMS. -
Page 15: Notifications
Notifications ONE PHONE can receive a SMS notification when the intercom triggers the gates. Turn this feature on and off quickly with this button. Enter your cell phone number here Enter a SMS message which will be sent each time the gates are triggered. E.g. “Gates Opened”... -
Page 16: After Hours
After Hours (Out of Hours) Once the do not disturb is set above, users can program the intercom to call an alternative phone number during do not disturb times rather than call no one. This is used for calling a security guard, site manager, or a different phone outside normal hours.
