• MAIN UNIT
(BOTTOM VIEW)
AF AMP
(IC55)
AF POWER AMP
CONTROLLER
(Q63)
PWR CTRL
(Q64)
1ST IF FILTER
(FI1)
1ST IF MIXER
(Q23)
IF DEMODULATOR IC
(IC3)
R5 LINE REGULATOR
(Q72)
AMP
(IC5)
AF CUSTOM IC
(IC2)
CLOCK AMP
(IC905)
POWER LINE SW
(Q92)
2 - 2
RF AMP
(Q22)
TX POWER AMP
(Q1)
DRIVE AMP
(Q2)
PRE-DRIVE AMP
(Q3)
PLL BUFFER
(Q9)
RIPPLE FILTER
(Q15)
CPU
(IC51)
