SECTION 7.
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6910021491 ANT CONNECTOR 106-1 <SSC>
SP1 2510001560 045P01202-02
W1 8900009640 OPC-963
MP1 8010022041 3286 CHASSIS-1 2X2 0
MP2 8210026490 3328 FRONT PANEL ASSEMBLY
MP10 8930082160 3285 NAME SHEET (A)
MP11 8930081140 3328 LENS
MP12 8930080620 O-RING (CF) <KRI>
MP13 8930080630 3285 SP PLATE Y1174
MP14 8930042350 1922 MIC SHEET
MP15 8930080410 3285 MIC SPONGE
MP16 8930079900 3285 TERMINAL HOLDER
MP17 8930080100 3285 PLUS TERMINAL
MP18 8930080400 3285 MINUS TERMINAL
MP19 8930084910 THERMAL SHEET (CB)TC200CAT20 (7.9X7.9)
MP20 8830003390 VR NUT (AB)
MP21 8930080092 3285 SIDE PLATE-2 Y1173B
MP22 8930080150 3285 SIDE SEAL <KRI>
MP23 8930080140 3285 TOP SEAL <KRI>
MP24 8830003440 3285 ANT NUT
MP25 8610014180 KNOB N-389
MP27 8610014190 KNOB N-390
MP31 8810008761 PHBT M2 X 8 NI-ZC3
MP32 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0)
MP33 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0)
MP34 8810009181 BT M2 X 5 NI-ZC3
MP35 8930066240 SPONGE (IM)
MP36 8930055051 THERMAL SHEET (V)-1 TC400HS (10X15)
[MAIN UNIT]
REF ORDER
NO. NO.
J51 6450000131 HSJ1102-018540
J52 6450002250 HSJ1456-010320
J53* 6510021901 BM02B-ASRS-TF (LF) (SN)
F51* 5210001160 ERBRE3R00V
MC51 7700002950 EM9745P-33-G <HOR>
S51 2260001900 SW-149 (SKHLLD)
S52* 2260002800 SW-167 (SKQTLAE010)
S53* 2260002800 SW-167 (SKQTLAE010)
S54 2250000830 FSR08-0008A <SLVJ>
MP2 8510016461 2775 VCO COVER-1
MP3* 8510016471 2775 VCO CASE-1
MP4* 6910014760 OG-503040
MP5* 6910014760 OG-503040
MP8* 8510020110 3328 SHIELD PLATE Y1222
MP9* 8510019920 3328 DSP CASE Y1212
MP10* 8510019930 3328 DSP COVER Y1213
MP11* 6910014760 OG-503040
MP12 8930082300 DOUBLE SIDE TAPE (BK)
MP13* 8930082310 3328 K-PLATE Y2158
MP16* 6910014760 OG-503040
MP18* 8930084710 FERRITE SHEET (AH)
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[ACCESSORIES]
REF ORDER
QTY.
NO. NO.
1 EP1 (Optional) FA-SC55V-2
EP2 (Optional) BP-265
EP3 (Optional) BC-193
1
EP4 (Optional) BC-123SA
1 (Optional) BC-123SE
1 MP1 (Optional) MB-124
1 MP2 8210025840 3285 JACK PANEL
1 MP3 8810004861 PH M2 X 6 ZK3
1
1
1
1
1
1
1
EP2*
1
1
2
1
1
1
1
1
1
2
9
1
2
1
1
QTY.
* Shape is different, depending on the version.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
7 - 1
DESCRIPTION
[USA-01]
[EXP-01]
EP1
EP3 EP4
MP1*
MP2
QTY.
1
1
1
1
1
1
1
2
MP3
