Icom IC-F3210D Service Manual page 25

[MAIN UNIT]
REF PARTS
NO. NO.
C951 4030016930 S.CER C1005 JB 1A 104K-T
C953 4030017460 S.CER C1005 JB 1H 102K-T
C954 4030016790 S.CER C1005 JB 1E 103K-T
C955 4030016930 S.CER C1005 JB 1A 104K-T
C956 4030017380 S.CER C1005 CH 1H 050B-T
C957 4030016930 S.CER C1005 JB 1A 104K-T
C958 4030016930 S.CER C1005 JB 1A 104K-T
J51 6450000131 CON HSJ1102-018540
J52 6450002250 CON HSJ1456-010320
J53 6510021901 S.CON BM02B-ASRS-TF(LF)(SN)
F51 5210001160 S.FUS ERBRE3R00V
DS51 5040003790 S.LED SML-522MU8WT86
MC51 7700002950 MIC EM9745P-33-G <HOR>
S51 2260001900 SWI SW-149 (SKHLLD)
S52 2260002800 S.SWI SW-167 (SKQTLAE010)
S53 2260002800 S.SWI SW-167 (SKQTLAE010)
S54 2250000830 ENC FSR08-0008A <SLVJ>
EP2 6910018460 S.BEA MMZ1005Y102C-T
EP3 6910018460 S.BEA MMZ1005Y102C-T
EP4 6910018460 S.BEA MMZ1005Y102C-T
EP5 6910018460 S.BEA MMZ1005Y102C-T
EP6 6910014730 S.BEA MPZ2012S331A-T
EP7 6910021240 S.BEA MMZ1005A152ET
EP8 6910021240 S.BEA MMZ1005A152ET
EP9 6910021630 S.BEA BLM18RK102SN1D
EP51 6910018460 S.BEA MMZ1005Y102C-T
EP52 6910021240 S.BEA MMZ1005A152ET
EP54 6910016330 S.BEA MMZ1005S 601CT-S
EP900 6910016330 S.BEA MMZ1005S 601CT-S
EP901 6910016330 S.BEA MMZ1005S 601CT-S
EP902 6910016330 S.BEA MMZ1005S 601CT-S
EP903 6910016330 S.BEA MMZ1005S 601CT-S
EP904 6910016330 S.BEA MMZ1005S 601CT-S
EP905 6910016330 S.BEA MMZ1005S 601CT-S
EP906 6910016330 S.BEA MMZ1005S 601CT-S
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B
B
B
B
B
B
T
T
T
T
B
B
B
B
T
T
B
B
B
B
B
B
B
B
B
B
T
T
B
B
H/V
78.0/46.9
80.5/48.6
82.3/48.6
78.7/43.8
79.9/42.9
78.7/42.6
68.5/38.2
27.2/34.5
10.7/37.6
2.0/37.9
39.2/1.9
48.7/1.9
32.8/15.5
63.5/21.3
45.2/28.7
41.0/11.0
25.2/21.4
61.1/30.4
60.9/33.1
57.1/29.6
19.1/46.2
96.5/13.0
69.9/37.2
71.1/43.9
76.7/41.9
74.5/38.1
83.2/49.7
94.4/47.0
84.5/49.8
93.2/46.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-5
S.=Surface mount
