FusionServer XH321C V6 Liquid-cooled Server Node
Technical White Paper
Issue
03
Date
2022-09-10
xFusion Digital Technologies Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FusionServer XH321C V6 and is the answer not in the manual?

Questions and answers

Related Manuals for xFusion Digital Technologies FusionServer XH321C V6

Summary of Contents for xFusion Digital Technologies FusionServer XH321C V6

  • Page 1 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper Issue Date 2022-09-10 xFusion Digital Technologies Co., Ltd.
  • Page 2 Notice In this document, "xFusion" is used to refer to "xFusion Digital Technologies Co., Ltd." for concise description and easy understanding, which does not mean that "xFusion" may have any other meaning. Any "xFusion" mentioned or described hereof may not be understood as any meaning other than "xFusion Digital Technologies Co., Ltd.", and xFusion Digital Technology Co., Ltd.

  • Page 3: Table Of Contents

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper Contents Contents About This Document ........................v 1 Overview ............................7 2 Product Features ..........................8 3 Physical Structure ........................11 4 Logical Structure ......................... 13 5 Hardware Description ........................ 15 5.1 Front Panel ..................................
  • Page 4 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper Contents 5.7 PSUs ................................... 32 5.8 Boards ..................................33 5.8.1 Mainboard ................................33 6 Product Specifications ........................ 35 6.1 Technical Specifications ............................. 35 6.2 Environmental Specifications ............................. 38 6.3 Physical Specifications ............................... 39 7 Software and Hardware Compatibility ..................

  • Page 5: About This Document

    Technical White Paper About This Document About This Document Purpose This document describes the FusionServer XH321C V6 server node in terms of features, structure, specifications, and component hardware and software compatibility. Intended Audience This document is intended for pre-sales engineers.
  • Page 6 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper About This Document Change History Issue Date Description 2022-09-10 Updated 6.2 Environmental Specifications. 2022-03-18 Updated 6.1 Technical Specifications and A.4 Sensor List. 2021-12-28 This issue is the first official release. 2022-09-10...

  • Page 7: Overview

    1 Overview Overview FusionServer XH321C V6 is a liquid-cooled server node designed for X6000 V6 servers. An X6000 V6 server can house up to four XH321C V6 server nodes in a 2 U chassis. The XH321C V6 delivers supreme performance and high storage density in limited space through innovative design.

  • Page 8: Product Features

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 2 Product Features Product Features Performance and Scalability ⚫ ® ® Powered by the third-generation Intel Xeon Scalable Ice Lake processors, the server provides up to 40 cores, 3.6 GHz frequency, a 60 MB L3 cache, and up to three 11.2 GT/s UPI links between the processors, which deliver supreme processing performance.
  • Page 9 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 2 Product Features ⚫ The server supports hot-swappable SAS/SATA/NVMe U.2 drives. SAS/SATA drives support RAID 0, 1, 5, 6, 10, 50, and 60, depending on the RAID controller card used. ⚫...
  • Page 10 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 2 Product Features Energy Efficiency ⚫ The server supports 80 Plus Platinum/Titanium PSUs of different energy efficiency levels. The PSU efficiency reaches 96% at 50% load. ⚫ ® ® Compared with the last-generation product, third-generation Intel...

  • Page 11: Physical Structure

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 3 Physical Structure Physical Structure Figure 3-1 XH321C V6 physical structure Screw-in RAID controller Cable management arm card Liquid cold plate TPM/TCM Memory modules Processors Mainboard Coin battery Server node case...
  • Page 12 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 3 Physical Structure OCP 3.0 network adapter Management network port board PCIe riser module M.2 SSD M.2 riser card 2022-09-10...

  • Page 13: Logical Structure

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 4 Logical Structure Logical Structure Figure 4-1 XH321C V6 logical structure ⚫ Scenario 1: CPU 1 and CPU 2 are connected to the pass-through PCIe riser card through PCIe x8 connectors respectively.
  • Page 14 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 4 Logical Structure ⚫ ® ® The server supports one or two third-generation Intel Xeon Scalable Ice Lake processors. ⚫ The server supports up to 16 memory modules. ⚫ The CPUs (processors) interconnect with each other through three UPI links at a speed of up to 11.2 GT/s.

  • Page 15: Hardware Description

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Hardware Description 5.1 Front Panel 5.2 Processors 5.3 Memory 5.4 Storage 5.5 Network 5.6 I/O Expansion 5.7 PSUs 5.8 Boards 5.1 Front Panel 5.1.1 Appearance Figure 5-1 Front view...

  • Page 16: Indicators And Buttons

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description SN label) NOTE The FlexIO card slot supports only OCP 3.0 network adapters. 5.1.2 Indicators and Buttons Indicator and Button Positions Figure 5-2 Indicators and buttons on the front panel...
  • Page 17 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Silkscreen Indicator/Butt Description Power button: ⚫ When the device is powered on, you can press this button to gracefully shut down the OS. NOTE For different OSs, you may need to shut down the OS as prompted.
  • Page 18 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Silkscreen Indicator/Butt Description ⚫ Connection Off: The network port is not connected. status indicator ⚫ Steady green: The network port is connected of the properly. management network port PSU indicator ⚫...

  • Page 19: Ports

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description 5.1.3 Ports Port Positions Figure 5-3 Ports on the front panel Water inlet Water outlet USB 3.0 Type-C port iBMC direct connect management port/debugging serial port Management network port...

  • Page 20: Installation Positions

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Port Type Quantity Description ⚫ iBMC direct USB Type-C Uses a USB Type-C cable to connect connect a local PC or mobile management phone to the server node iBMC...

  • Page 21: Processors

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Figure 5-4 Installation positions When installing a server node, ensure that the exposed connectors on the front of the server node do not collide with the chassis or other objects.

  • Page 22: Memory

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description 5.3 Memory 5.3.1 DDR4 Memory 5.3.1.1 Memory Identifier You can determine the memory module properties based on the label attached to the memory module. Figure 5-6 Memory identifier...

  • Page 23: Memory Subsystem Architecture

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description 5.3.1.2 Memory Subsystem Architecture A server provides 16 memory slots. Each processor integrates eight memory channels. Table 5-3 Memory channels Memory Channel Memory Slot CPU1 DIMM000(A) DIMM010(B) DIMM020(C)
  • Page 24 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description ⚫ A server must use DDR4 memory modules of the same part number (P/N code), and the memory speed is the minimum value of the following items: ⚫...

  • Page 25: Dimm Installation Rules

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Parameter Specifications configuration. The value is halved for a server with only one processor. ⚫ b: DPC (DIMM per channel) indicates the number of memory modules per channel.
  • Page 26 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Figure 5-7 Memory slots Figure 5-8 DDR4 memory module installation guidelines (1 processor) 2022-09-10...

  • Page 27: Memory Protection Technologies

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Figure 5-9 DDR4 memory module installation guidelines (2 processors) 5.3.1.6 Memory Protection Technologies The following memory protection technologies are supported: ⚫ ⚫ Memory Mirroring ⚫ Memory Single Device Data Correction (SDDC) ⚫...

  • Page 28: Memory Protection Technologies

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description ⚫ Memory Demand/Patrol Scrubbing ⚫ Memory Data Scrambling ⚫ Post Package Repair (PPR) ⚫ Write Data CRC Protection ⚫ Adaptive Data Correction - Single Region (ADC-SR) ⚫ Adaptive Double Device Data Correction - Multiple Region (ADDDC-MR) ⚫...

  • Page 29: Drive Numbering

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description 5.4.2 Drive Numbering Figure 5-10 Drive numbering 5.4.3 RAID Controller Card The RAID controller card supports RAID configuration, RAID level migration, and drive roaming. ⚫ Contact your local sales representative or see "Search Parts" in the...

  • Page 30: I/O Expansion

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description ⚫ Contact your local sales representative or see "Search Parts" in the Compatibility Checker to determine the components to be used. ⚫ For details about the OCP 3.0 network adapter, see the documents of each OCP 3.0 network adapter.

  • Page 31: Pcie Slot Description

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description Figure 5-12 PCIe riser module 5.6.3 PCIe Slot Description The PCIe slots mapping to a vacant CPU socket are unavailable. Table 5-6 PCIe slot description PCIe PCIe Connect...

  • Page 32: Psus

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description PCIe PCIe Connect Port Root Slot Size Standar Port Slot Width (B/D Width connected to the PCIe x8 bus connector of CPU 1, so the slot 1 supports the multi-host feature (the x16 bus of the slot is connected to two processors through two x8 cables).

  • Page 33: Boards

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description 5.8 Boards 5.8.1 Mainboard Figure 5-14 XH321C V6 mainboard Liquid leakage sensor PCIe riser card connector connector (LIQUID (PCIE RISER x16/J31) DET/J7&J8) Node I/O card cable connector NC-SI connector (NCSI...
  • Page 34 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 5 Hardware Description (CPU1)/J11) GE management network port VROC key connector (SOFT board connector (GE RAID KEY/J3) CONN/J27) OCP 3.0 network adapter Cell battery holder (U9) connector (OCP CONN/J108) a: Reserved and unavailable currently.

  • Page 35: Product Specifications

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 6 Product Specifications Product Specifications 6.1 Technical Specifications 6.2 Environmental Specifications 6.3 Physical Specifications 6.1 Technical Specifications Table 6-1 Technical specifications Category Specifications Form factor 2U4 liquid-cooled server node ® Chipset...
  • Page 36 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 6 Product Specifications Category Specifications ⚫ RDIMM and LRDIMM support ⚫ The DDR4 memory modules of different types (RDIMM and LRDIMM) and specifications (capacity, bit width, rank, and height) cannot be used together.
  • Page 37 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 6 Product Specifications Category Specifications The OCP 3.0 network adapter supports orderly hot swap only when the VMD function is disabled. − Supports a variety of OCP 3.0 network adapters. For details, see "Search Parts"...

  • Page 38: Environmental Specifications

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 6 Product Specifications 6.2 Environmental Specifications Table 6-2 Environmental Specifications Category Specifications ⚫ Temperature Operating temperature: 5° C to 45° C (41° F to 113° F) (ASHRAE Classes A1 to A4 compliant) Storage temperature (within three months): –30°...

  • Page 39: Physical Specifications

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 6 Product Specifications Category Specifications ⚫ There is no explosive, conductive, magnetic, or corrosive dust in the equipment room. NOTE It is recommended that the particulate pollutants in the equipment room be monitored by a professional organization.
  • Page 40 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 6 Product Specifications Item Description Figure 6-1 shows how to measure the physical dimensions of a server node. Weight in full ⚫ Net weight: 7.5 kg (16.53 lb) configuration ⚫ Packing material weight: 3.2 kg (7.05 lb)

  • Page 41: Software And Hardware Compatibility

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 7 Software and Hardware Compatibility Software and Hardware Compatibility Use the Compatibility Checker to obtain information about the operating systems and hardware supported. ⚫ If incompatible components are used, the device may be abnormal. This fault is beyond the scope of technical support and warranty.

  • Page 42: Safety Instructions

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 8 Safety Instructions Safety Instructions 8.1 Security 8.2 Maintenance and Warranty 8.1 Security General Statement ⚫ Comply with local laws and regulations when installing devices. These Safety Instructions are only a supplement.
  • Page 43 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 8 Safety Instructions Figure 8-1 Safety work wear ⚫ Before touching a device, wear ESD clothing and gloves (or wrist strap), and remove any conductive objects (such as watches and jewelry). Figure 8-2 shows conductive objects that must be removed before you touch a device.
  • Page 44 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 8 Safety Instructions Figure 8-3 Wearing an ESD wrist strap ⚫ Exercise caution when using tools. ⚫ If the installation position of a device is higher than the shoulders of the installation personnel, use a vehicle such as a lift to facilitate installation.

  • Page 45: Maintenance And Warranty

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 8 Safety Instructions ⚫ Transport each device in its original packaging. ⚫ If the original packaging is unavailable, package heavy, bulky parts (such as chassis and blades) and fragile parts (such as PCIe cards and optical modules) separately.

  • Page 46: System Management

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 9 System Management System Management This product integrates the new-generation Intelligent Baseboard Management Controller (iBMC), which complies with Intelligent Platform Management Interface 2.0 (IPMI 2.0) specifications and provides reliable hardware monitoring and management.
  • Page 47 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 9 System Management ⚫ System maintenance interface − The virtual KVM and virtual media functions facilitate remote maintenance. − The iBMC supports out-of-band RAID monitoring and configuration to improve RAID configuration efficiency and management capabilities.

  • Page 48: Certifications

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 10 Certifications Certifications Country/Region Certification Standards Europe WEEE 2012/19/EU Europe REACH EC NO. 1907/2006 Europe Safety: EN 62368-1:2014+A11:2017 EMC: EN 55032:2015+A11:2020 CISPR 32:2015+A1:2019 EN IEC 61000-3-2:2019+A1:2021 EN 61000-3-3:2013+A1:2019 EN 55035:2017+A11:2020 CISPR 35:2016...
  • Page 49 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper 10 Certifications Country/Region Certification Standards CISPR 35:2016 EN 55024:2010+A1:2015 CISPR 24:2010+A1:2015 ETSI EN 300 386 V1.6.1:2012 ETSI EN 300 386 V2.1.1:2016 RoHS: BS EN IEC 63000:2018 ErP: Commission Regulation(EU) 424/2019 China GB 17625.1-2012...

  • Page 50: A Appendix

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper A Appendix Appendix A.1 Node Label Information The label information and location are for reference only. For details, see the actual product. A.1.1 Node Label Figure A-1 Label position Table A-1 Label description Description Serial number of the server node.
  • Page 51 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper A Appendix A.2 Product SN The serial number (SN) on the slide-out label plate uniquely identifies a device. The SN is required when you contact technical support. Figure A-2 SN example...
  • Page 52 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper A Appendix A.4 Sensor List Sensor Description Component Inlet Temp Air inlet temperature Left mounting ear Outlet Temp Air outlet temperature Mainboard RAID BBU Temp RAID controller card capacitor RAID controller card...
  • Page 53 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper A Appendix Sensor Description Component SYS_12V_MB1 Mainboard 12.0 V voltage Component in position U12409 on the mainboard SYS_12V_MB2 Component in position U12408 on the mainboard SYS_12V_VSBY Component in position U44 on the...
  • Page 54 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper A Appendix Sensor Description Component to 4. PowerN PSU input power PSU N N indicates the PSU number. The value is 1 or 4. CPU Usage CPU usage. Mainboard Memory Usage Memory usage.
  • Page 55 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper A Appendix Sensor Description Component The value ranges from 0 to 5. FANN Presence Fan presence Fan module N N indicates the fan module number. The value ranges from 1 to 4.
  • Page 56 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper A Appendix Sensor Description Component Sec. Log Full Security log full or clearing events SSD DiskN Temp SSD temperature SSD drive N N indicates the drive slot number. The value ranges from 0 to 5.

  • Page 57: B Glossary

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper B Glossary Glossary B.1 A-E The baseboard management controller (BMC) complies with the Intelligent Platform Management Interface (IPMI). It collects, processes, and stores sensor signals, and monitors the operating status of components. The BMC provides the...
  • Page 58 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper B Glossary hot swap Replacing or adding components without stopping or shutting down the system. B.3 K-O A hardware device that provides public video, keyboard and mouse (KVM). B.4 P-T panel An external component (including but not limited to ejector levers, indicators, and ports) on the front or rear of the server.
  • Page 59 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper B Glossary system event log Event records stored in the system used for subsequent fault (SEL) diagnosis and system recovery. B.5 U-Z A unit defined in International Electrotechnical Commission (IEC) 60297-1 to measure the height of a cabinet, chassis, or subrack.

  • Page 60: C Acronyms And Abbreviations

    FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper C Acronyms and Abbreviations Acronyms and Abbreviations C.1 A-E alternating current Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System baseboard management controller...
  • Page 61 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper C Acronyms and Abbreviations direct current DDR4 Double Data Rate 4 DDDC double device data correction DEMT Dynamic Energy Management Technology DIMM dual in-line memory module DRAM dynamic random-access memory digital video disc...
  • Page 62 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper C Acronyms and Abbreviations high availability hard disk drive high-performance computing HTTP Hypertext Transfer Protocol HTTPS Hypertext Transfer Protocol Secure iBMC intelligent baseboard management controller Industry Canada ICMP Internet Control Message Protocol...
  • Page 63 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper C Acronyms and Abbreviations LRDIMM load-reduced dual in-line memory module light emitting diode LAN on motherboard media access control module management controller next business day NC-SI Network Controller Sideband Interface Open Compute Project C.4 P-T...
  • Page 64 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper C Acronyms and Abbreviations reliability, availability and serviceability RDIMM registered dual in-line memory module REACH Registration Evaluation and Authorization of Chemicals RJ45 registered jack 45 RoHS Restriction of the Use of Certain Hazardous Substances in...
  • Page 65 FusionServer XH321C V6 Liquid-cooled Server Node Technical White Paper C Acronyms and Abbreviations Trusted Execution Technology TransFlash module TFTP Trivial File Transfer Protocol TCP offload engine trusted platform module C.5 U-Z UDIMM unbuffered dual in-line memory module UEFI Unified Extensible Firmware Interface unit identification light Underwriter Laboratories Inc.
