CIS VCC-G20E30B Product Specification & Operational Manual

Analog i/f, 29mm cubic eia analog b/w camera

Advertisement

Quick Links

VCC-G20E30B
Rev.900-718-34
English
Analog I/F
29mm Cubic EIA
Analog B/W Camera
VCC-G20E30B
Product Specification
& Operational Manual
CIS Corporation
©2014 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-G20E30B and is the answer not in the manual?

Questions and answers

Summary of Contents for CIS VCC-G20E30B

  • Page 1 VCC-G20E30B Rev.900-718-34 English Analog I/F 29mm Cubic EIA Analog B/W Camera VCC-G20E30B Product Specification & Operational Manual CIS Corporation ©2014 CIS Corporation. All rights reserved.
  • Page 2: Table Of Contents

    7.3. Vertical Sync Timing (Frame Storage) ............15 8. CCD Optical Axis Accuracy ..............16 9. Dimensions ................... 17 10. Cases for Indemnity (Limited Warranty) ............18 11. CCD Pixel Defect ................18 12. Product Support ................18 ©2014 CIS Corporation. All rights reserved.
  • Page 3: Scope Of Application

    VCC-G20E30B Rev.900-718-34 1. Scope of Application This is to describe VCC-G20E30B analog EIA B/W CCD Camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life.
  • Page 4: Product Outline

    VCC-G20E30B Rev.900-718-34 3. Product Outline VCC-G20E30B is a high-resolution industrial B/W analog camera module utilizing a 1/3 type TV format CCD. 380K pixels CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. Key Features HD/VD sync input or Trigger input are valid.
  • Page 5: Specification

    1.5 W typ (max. 1.8W) at DC +12V IN Refer to overall dimension drawing (Clause 9) Dimension 29mm x 29mm x 29mm (excluding projection) Mass Approx. 45 gs Lens mount C mount (Refer to overall dimension drawing) ©2014 CIS Corporation. All rights reserved.
  • Page 6 Shock Y, ±Z, 6 directions. (without package) Operation guaranteed: -5℃~+45℃ Temperature Performance guaranteed: 0℃~+40℃ Operation environment RH 20~80% with no condensation Humidity -25℃ ~ +60℃ Temperature Storage environment RH 20~80% with no condensation Humidity ©2014 CIS Corporation. All rights reserved.
  • Page 7: Camera Input/Output Signal Specification

    Trigger IN 47pF Video signal VS output 1.0V (p-p), Sync. Negative, 75Ω unbalanced, DC connect White clip level: 820 ± 70 mVp-p Setup level: 20 ± 15 mVp-p SYNC level: 290 ± 50 mVp-p ©2014 CIS Corporation. All rights reserved.
  • Page 8: Ccd Spectral Response (Representative Value)

    75ohm ● ◇30fps CLK = 14.318MHz/ 60fps CLK = 28.636MHz Speed ● ◇HD/VD signal input and output setting (No. 6 & 7 pin of 12pins IN/OUT ● circular connector.) Indicates initial setting position. ● ©2014 CIS Corporation. All rights reserved.
  • Page 9 Normal Shutter Mode Restart/Reset Mode Fixed Trigger Shutter Mode (SYNC Reset Mode) (SYNC Non Reset Mode) 〃 Pulse Width Trigger Shutter Mode (SYNC Reset Mode) (SYNC Non Reset Mode) 〃 Indicates initial setting position ©2014 CIS Corporation. All rights reserved.
  • Page 10 ODD/EVEN field is determined by EXT HD/VD phase. External HD External VD (Internal VD) 262.5H min (1V min) ODD Field Exposure EVEN Field Exposure Video Output ODD Image EVEN Image 242.5H 252.5H WEN Output ©2014 CIS Corporation. All rights reserved.
  • Page 11 Exposure time = when setting with switch SW 1 ~4: 1/100 ~ 1/10000s at 30fps. 1/200 ~ 1/20000s at 60fps. Trigger Input Pulse Width: 4μs~250ms Exposure Time Setting time by Rear dip switch External HD External VD (Internal VD) 10μs~65ms Video Output 242.5H 252.5H WEN Output ©2014 CIS Corporation. All rights reserved.
  • Page 12 Trigger Pulse Width (μs) +48μs at 60fps. Trigger Input Pulse Width: 4μ s~250ms Exposure Time Setting time by (Trigger Pulse Width + 96μ s) External HD External VD (Internal VD) 10μ s~65ms Video Output 242.5H 252.5H WEN Output ©2014 CIS Corporation. All rights reserved.
  • Page 13 CLK= 14.318MHz 60fps Mode CLK= 28.636MHz When changing pixel clock, please reboot the camera power. HD/VD Input and Output Selection HD/VD Output SW10 HD/VD Input (Internal/External Sync can be recognized automatically.) Indicates initial setting position ©2014 CIS Corporation. All rights reserved.
  • Page 14: External Connector Pin Assignment

    VCC-G20E30B Rev.900-718-34 6. External Connector Pin Assignment 12 pins Circular Connector SNH-10-12(RPCB) (SAMWOO) Pin No. Power In DC+12V Video Out HD In/Out VD In/Out WEN Out Trig In ©2014 CIS Corporation. All rights reserved.
  • Page 15: Timing Chart

    ODD Field 262.5H EVEN Field 262.5H Camera VD CCD Output Transmit Black Effective Lines Transmit Black Effective Lines Video Output Vertical Blanking Video Active Period Vertical Blanking Video Active Period 242.5H 242.5H WEN Output ©2014 CIS Corporation. All rights reserved.
  • Page 16: Ccd Optical Axis Accuracy

    ?? ±0.5° The center of effective pixels shall be within f 0.6 to the center of lens mount. (*) Dimension from datum plane to the center of lens mount. 910-015-00-00 (Unit : mm) ©2014 CIS Corporation. All rights reserved.
  • Page 17: Dimensions

    VCC-G20E30B Rev.900-718-34 9. Dimensions ©2014 CIS Corporation. All rights reserved.
  • Page 18: Cases For Indemnity (Limited Warranty)

    11. CCD Pixel Defect After delivery, CCD pixel defects might be noted with time of usage of the products. The cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS shall be exempted from taking responsibility on it.
