DGS0028A
PIN 1 INDEX
AREA
A
1
7.2
7.0
NOTE 3
14
B
SEE DETAIL A
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions, or gate burrs shall not
exceed 0.15 mm per side.
4. No JEDEC registration as of September 2020.
5. Features may differ or may not be present.
5.1
TYP
4.7
28
2X 6.5
15
3.1
2.9
4X (7 -15 )
GAGE PLANE
www.ti.com
PACKAGE OUTLINE
VSSOP - 1.1 mm max height
0.1 C
26X 0.5
4X (0 -15 )
0.275
28X
0.165
0.1 C A B
(0.15) TYP
0.25
0 -8
PowerPAD is a trademark of Texas Instruments.
SMALL OUTLINE PACKAGE
C
SEATING
PLANE
1.1 MAX
0.7 0.15
0.4
0.05
DETAIL A
A 2 0
TYPICAL
4226365/A 10/2020
