Texas Instruments MSP430F4152IPM Manual

Low Supply-Voltage Range, 1.8 V to 3.6 V
D
Ultralow Power Consumption
D
Active Mode: 220 A at 1 MHz, 2.2 V
Standby Mode: 0.9 A
Off Mode (RAM Retention): 0.1 A
Five Power-Saving Modes
D
Wake-Up From Standby Mode in Less
D
Than 6 s
- - Internal Very Low Power,
Low-Frequency Oscillator
16-Bit RISC Architecture,
D
125-ns Instruction Cycle Time
16-Bit Timer_A With Three
D
Capture/Compare Registers
16-Bit Timer_A With Five Capture/Compare
D
Registers
Two Universal Serial Communication
D
Interfaces (USCIs)
USCI_A0
- - Enhanced UART Supporting
Auto-Baudrate Detection
- - IrDA Encoder and Decoder
- - Synchronous SPI
USCI_B0
- - I2C
- - Synchronous SPI
Supply Voltage Supervisor/Monitor With
D
Programmable Level Detection
description
The Texas Instruments MSP430 family of ultralow-power microcontrollers consist of several devices featuring
different sets of peripherals targeted for various applications. The architecture, combined with five low power
modes, is optimized to achieve extended battery life in portable measurement applications. The device features
a powerful 16-bit RISC CPU, 16-bit registers, and constant generator that contribute to maximum code
efficiency. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less
than 6 s.
The MSP430F41x2 is a microcontroller configuration with two 16-bit timers, a basic timer with a real--time clock,
a 10-bit A/D converter, a versatile analog comparator, two universal serial communication interfaces, up to 48
I/O pins, and a liquid crystal display driver.
Typical applications for this device include analog and digital sensor systems, remote controls, thermostats,
digital timers, hand-held meters, etc.
This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling and installation procedures can cause damage. ESD damage can range
from subtle performance degradation to complete device failure. Precision integrated circuits may be more susceptible to damage
because very small parametric changes could cause the device not to meet its published specifications. These devices have limited
built-in ESD protection.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
Integrated LCD Driver With Contrast
D
Control for Up to 144 Segments
Basic Timer With Real Time Clock Feature
D
Brownout detector
D
On-Chip Comparator for Analog Signal
D
Compare Function or Slope A/D
10-Bit 200-ksps Analog-to-Digital (A/D)
D
Converter With Internal Reference,
Sample-and-Hold, Autoscan, and Data
Transfer Controller
Serial Onboard Programming,
D
No External Programming Voltage Needed
Programmable Code Protection by Security
Fuse
Bootstrap Loader
D
On-Chip Emulation Module
D
Family Members Include:
D
MSP430F4152: 16KB+256B Flash Memory
MSP430F4132: 8KB+256B Flash Memory
Available in 64-Pin QFP Package and
D
48-Pin QFN Package (See Available
Options)
For Complete Module Descriptions, See
D
The MSP430x4xx Family User's Guide,
Literature Number SLAU056

