www.ti.com
PA0 / FCC_IN
PA1
PA28
NRST
PA31 / CLK_OUT
VDD
VSS
PA2 / ROSC
PA3 / LFXIN
PA4 / LFCLK_IN / LFXOUT
PA5 / HFXIN / FCC_IN
PA6 / HFCLK_IN / HFXOUT
Copyright © 2023 Texas Instruments Incorporated
1
2
3
4
5
6
VQFN48
7
8
9
10
11
12
Figure 6-4. 48-Pin RGZ (VQFN) (Top View)
Product Folder Links:
MSPM0G3507 MSPM0G3506 MSPM0G3505
MSPM0G3507, MSPM0G3506, MSPM0G3505
SLASEX6A – FEBRUARY 2023 – REVISED JUNE 2023
36
PB17 / A1_4
35
PA20 / SWCLK
34
PA19 / SWDIO
33
PA18 / A1_3
32
PA17 / A1_2
31
PA16 / A1_1 /FCC_IN
30
PA15 / A1_0
29
PA14 / CLK_OUT / A0_12
28
PA13
27
PA12 / FCC_IN
26
PB16
25
PB15
Thermal pad
Submit Document Feedback
9
