Summary of Contents for Eliminator Lighting EM30
- Page 1 EM30 User Manual...
- Page 2 All non-Eliminator brands and product names are trademarks or registered trademarks of their respective companies. Eliminator Lighting and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic...
-
Page 3: Table Of Contents
C O N T E N T S General Information Limited Warranty (USA Only) Safety Guidelines Maintenance Guidelines Overview Installation Guidelines Frequently Asked Questions Specifications | Dimensional Drawings... -
Page 4: General Information
G E N E R A L I N F O R M AT I O N INTRODUCTION Please read and understand all instructions in this manual carefully and thoroughly before attempting to operate this product. These instructions contain important safety and use information. UNPACKING This device has been thoroughly tested and has been shipped in perfect operating condition. -
Page 5: Limited Warranty (Usa Only)
ADJ Products, LLC Service Department at 800-322-6337. Send the product only to the Eliminator Lighting factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, Eliminator Lighting will pay return shipping charges only to a designated point within the United States. -
Page 6: Safety Guidelines
To guarantee a smooth operation, it is important to follow all instructions and guidelines in this man- ual. ELIMINATOR LIGHTING is not responsible for injury and/or damages resulting from the misuse of these devices due to the disregard of the information printed in this manual. Only qualified and/ or certified personnel should perform installation of these devices and only the original rigging parts included with these devices should be used for installation. -
Page 7: Maintenance Guidelines
Regular inspections are recommended to ensure proper function and extended life. There are no user serviceable parts inside these devices. Please refer all other service issues to Eliminator Lighting. Should you need any spare parts, please order genuine parts from Eliminator Lighting. -
Page 8: Overview
O V E R V I E W Primary Secondary Mounting Mounting Loop Loop Mirror Ball... -
Page 9: Installation Guidelines
I N S TA L L AT I O N G U I D E L I N E S FLAMMABLE MATERIAL WARNING Keep devices at least 5.0 ft (1.5m) away from flammable materials and/or pyrotechnics. DO NOT INSTALL THE DEVICE IF YOU LACK THE RELEVANT QUALIFICATIONS! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, INCLUDING BUT NOT LIMITED TO CALCULATING WORKING LOAD LIMITS, KNOWLEDGE OF INSTALLATION MATERIAL BE- ING USED, AND PERIODIC SAFETY INSPECTION OF ALL INSTALLATION MATERIAL. - Page 10 I N S TA L L AT I O N G U I D E L I N E S • The mirror ball unit includes two separate mounting eyelets. The eyelet located at the center of the top of the mirror ball should be used as the primary mounting point, while the eyelet located slightly off-center should be used as the secondary mounting point.
- Page 11 I N S TA L L AT I O N G U I D E L I N E S SAFETY CABLE ATTACHMENT Use of a secondary safety cable is required. To install, attach a safety cable to the mirror ball eyelet and the motor safety eyelet or mounting fixture.
- Page 12 I N S TA L L AT I O N G U I D E L I N E S LIGHTING THE MIRROR BALL Experiment with different angles and distances to achieve the desired result.
-
Page 13: Frequently Asked Questions
F R E Q U E N T LY A S K E D Q U E S T I O N S Can the EM30 be mounted to a ceiling? Yes, it may be installed onto a flat ceiling surface that can support 10 times the combined total weight of the attached mirror ball, motor and any mounting accessories. -
Page 14: Specifications | Dimensional Drawings
S P E C I F I C AT I O N S Model: EM30 Mirror Ball Body Diameter: 29.7 in (755mm) Weight: 32.18 lbs / 14.6 kg D I M E N S I O N A L D R AW I N G S... - Page 15 This page intentionally left blank.
