Summary of Contents for Maytronics ACTIVE 6
- Page 1 M600 / ZENIT 60 / ACTIVE 6 / ACTIVE X6 / ACTIVE ULTIMATE Maytronics Dolphin robotic pool cleaner User Instructions 8180002...
-
Page 2: Table Of Contents
M600 / ZENIT 60 / ACTIVE 6 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner User Instructions Contents 1. INTRODUCTION ..............................2 2. SPECIFICATIONS ..............................2 3. WARNINGS AND CAUTIONS ..........................2 3.1 Water conditions ............................3 4. ROBOTIC POOL CLEANER PARTS ........................4 5. -
Page 3: Introduction
1. INTRODUCTION Thank you for purchasing a Maytronics Robotic Pool Cleaner. We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient, and cost-effective pool cleaning, to enhance your pool’s hygiene. Robotic Pool Cleaners by Maytronics deliver advanced cleaning technologies, exceptional ease of use, long-lasting performance, and simple maintenance. -
Page 4: Water Conditions
The unit must be connected only to a supply circuit that is protected by a ground-fault circuit interrupter (GFCI). This GFCI should be tested on a routine basis. To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button. Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. -
Page 5: Robotic Pool Cleaner Parts
4. ROBOTIC POOL CLEANER PARTS Robotic Pool Cleaner Power supply Filtration Start the season with the net filters for large debris then use ultra-fine filters for daily use. * The net filters are assembled in the filter basket. Caddy kit M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner User Instructions... -
Page 6: Using The Robotic Pool Cleaner
5. USING THE ROBOTIC POOL CLEANER minimum 5.1 Setup Before using the Robotic Pool Cleaner for the first time, perform the following steps: minimum 5.1.1 5.1.2 Position the power supply Unwind the cable and stretch it out completely so that it at approximately the middle of the has no kinks. -
Page 7: Placing The Robotic Pool Cleaner Into The Pool
5.2 Placing the Robotic Pool Cleaner into the pool 5.2.1 Place the Robotic Pool Cleaner in the pool. Release it and let it sink to the floor of the pool. Make sure that the floating cable is free of any obstacles. 5.3 Plug in the power supply minimum 5.3.1... -
Page 8: Operating The Robotic Pool Cleaner Without Using Your Smart Device
5.4 Operating the Robotic Pool Cleaner without using your smart device Press the power button to turn the robot ON. The Robotic Pool Cleaner will now operate until it has reached the end of the cleaning cycle. 5.5 Using the power supply Your power supply is designed to provide you with the most advanced features to improve your experience. -
Page 9: Removing The Robotic Pool Cleaner From The Pool
5.7 Removing the Robotic Pool Cleaner from the pool Option A The easiest and most fun way to get the robot out of the water: 1. Log into the MyDolphin™ Plus app and click "Pick-up mode". 2. The robot will reach the wall closest to it and will rise above the water surface. 3. -
Page 10: Care And Maintenance
6. CARE AND MAINTENANCE Make sure the power supply is switched off. WARNING We highly recommend cleaning the filter basket after each cleaning cycle. Note: Do not let the filter panels dry out before cleaning. 6.1 Cleaning after use - Removing and cleaning the dual filter basket click! 6.1.2 6.1.1... -
Page 11: Periodic Filter Cleaning
6.2 Periodic filter cleaning - Recommended at least once a month Dismantle the 4 ultra-fine filter panels of the outer basket, according to the following steps: 6.2.3 6.2.1 6.2.2 Hold down the Dismantle the Continue to dismantle the panels in order: 2 — > 3 — > 4. handle to remove the panels;... -
Page 12: Cleaning The Impeller
6.3 Cleaning the impeller If you notice debris trapped in the impeller: Make sure the power supply is switched off and unplugged. WARNING Clean the debris trapped in the impeller opening, according to the following steps: 6.3.1 6.3.2 6.3.3 6.3.4 M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner User Instructions... -
Page 13: Periodic General Maintenance - Recommended At Least Once A Week
Assemble the impeller compartment according to the next steps: 6.3.6 6.3.5 6.4 Periodic general maintenance - Recommended at least once a week • When the cable is wet, spread it flat and straight in the yard, and allow it to dry for at least five hours to avoid twisting of the cable. -
Page 14: Use The Mydolphin™ Plus Iot Mobile App
8. USE THE MyDolphin™ Plus IOT MOBILE APP Please download the Maytronics MyDolphin™ Plus app to your mobile smart device from either Google Play for Android or the Appstore for iOS. The Maytronics MyDolphin™ Plus app is cloud-connected, enabling control from anywhere at anytime, with real-time connectivity. -
Page 15: Led Lights
8.4 LED Lights Connectivity LEDs The connectivity LED light on the power supply has several modes: 1. Flashing blue light - waiting for Bluetooth® connection. 2. Steady blue light - connected via Bluetooth®. 3. Flashing green light - power supply is connected to your home/pool Wi-Fi® network and trying to connect to the cloud. -
Page 16: Troubleshooting
9. TROUBLESHOOTING Unplug the power supply before performing any action. WARNING Symptom Possible reason Corrective action The power supply • No voltage in the power socket in the wall. • Check that there is voltage in the power socket in the wall. or its switch LED •... - Page 17 Symptom Possible reason Corrective action Can not connect • The power supply is too far from the router • Reset the power supply (disconnect the power cord), to your Wi-Fi®, and (weak signal) or your router is not working and wait 1 min. the communication properly.
-
Page 18: Mydolphin™ Plus - Troubleshooting
10. MyDolphin™ Plus - TROUBLESHOOTING Before using the app, make sure you have: • Cellular connection 3G/4G/5G or Wi-Fi®, with strong signal strength • Power supply support 2.4Ghz ONLY • Bluetooth® enabled Action What To Do Pool cleaner does not connect to Wi-Fi®, and power supply is trying to connect to your home/pool Wi-Fi®... - Page 19 → The MU will link to robot and the app → home screen. If you do not recognize the serial number, press to add the robot s/n manually or scan the QR Code. If none of these solutions do not solve your problem, contact Maytronics Customer Care: North America 1-888-365-7446 ext. 1002 customersupport@maytronicsus.com...
