- Page 1 M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Maytronics Dolphin robotic pool cleaner User Instructions 8180002...
-
Page 2: Table Of Contents
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner User Instructions Contents 1. INTRODUCTION ..............................2 2. SPECIFICATIONS ..............................2 3. WARNINGS AND CAUTIONS ..........................2 3.1 Water conditions ............................3 3.2 Important: Setting up the Wi-Fi® ......................3 4. ROBOTIC POOL CLEANER PARTS ........................4 5. -
Page 3: Introduction
1. INTRODUCTION Thank you for purchasing a Maytronics Robotic Pool Cleaner. We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient, and cost-effective pool cleaning, to enhance your pool’s hygiene. Robotic Pool Cleaners by Maytronics deliver advanced cleaning technologies, exceptional ease of use, long-lasting performance, and simple maintenance. -
Page 4: Water Conditions
To reduce the risk of electric shock replace damaged cord immedietely. Do not use extension cord to connect unit to electric supply; provide a properly located outlet. WARNING Please ensure that the following PRECAUTIONS are implemented: Operator should keep hands away from driving belt mechanism. CAUTION Position the Caddy and power supply at least 3.5m/12ft from pool’s edge –... -
Page 5: Robotic Pool Cleaner Parts
4. ROBOTIC POOL CLEANER PARTS Robotic Pool Cleaner Power supply Filtration Start the season with the net filters for large debris then use ultra-fine filters for daily use. * The net filters are assembled in the filter basket. Caddy kit M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner User Instructions... -
Page 6: Using The Robotic Pool Cleaner
5. USING THE ROBOTIC POOL CLEANER 5.1 Setup Before using the Robotic Pool Cleaner for the first time, perform the following steps: 5.1.1 5.1.2 Position the power supply Unwind the cable and stretch it out completely so that it at approximately the middle of the has no kinks. -
Page 7: Placing The Robotic Pool Cleaner Into The Pool
5.2 Placing the Robotic Pool Cleaner into the pool 5.2.1 Place the Robotic Pool Cleaner in the pool. Release it and let it sink to the floor of the pool. Make sure that the floating cable is free of any obstacles. 5.3 Connecting the robot to your smart device (Phone or tablet) Please follow these simple steps: Download the MyDolphin™... -
Page 8: Operating The Robotic Pool Cleaner Without Using Your Smart Device
5.4 Operating the Robotic Pool Cleaner without using your smart device Press the power button to turn the robot ON. The Robotic Pool Cleaner will now operate until it has reached the end of the cleaning cycle. 5.5 Using the power supply Your power supply is designed to provide you with the most advanced features to improve your experience. -
Page 9: Removing The Robotic Pool Cleaner From The Pool
5.7 Removing the Robotic Pool Cleaner from the pool Turn OFF and unplug the power supply. WARNING 5.7.1 5.7.2 Use the floating cable to pull the Robotic Pool Cleaner to the side of the pool. Use the handle to remove the robot from the pool. DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE. -
Page 10: Care And Maintenance
6. CARE AND MAINTENANCE Make sure the power supply is switched off and unplugged. WARNING We highly recommend cleaning the filter basket after each cleaning cycle. Note: Do not let the filter panels dry out before cleaning. 6.1 Cleaning after use - Removing and cleaning the dual filter basket click! 6.1.2 6.1.1... -
Page 11: Periodic Filter Cleaning - Recommended At Least Once A Month
6.2 Periodic filter cleaning - Recommended at least once a month Dismantle the 4 ultra-fine filter panels of the outer basket, according to the following steps: 6.2.3 6.2.1 6.2.2 Hold down the Dismantle the Continue to dismantle the panels in order: 2 — > 3 — > 4. handle to remove the panels;... -
Page 12: Cleaning The Impeller
6.3 Cleaning the impeller If you notice debris trapped in the impeller: Make sure the power supply is switched off and unplugged. WARNING Clean the debris trapped in the impeller opening, according to the following steps: 6.3.1 6.3.2 6.3.3 6.3.4 M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner User Instructions... -
Page 13: Periodic General Maintenance - Recommended At Least Once A Week
Assemble the impeller compartment according to the next steps: 6.3.6 6.3.5 6.4 Periodic general maintenance - Recommended at least once a week • When the cable is wet, spread it flat and straight in the yard, and allow it to dry for at least five hours to avoid twisting of the cable. -
Page 14: Troubleshooting
8. TROUBLESHOOTING If the suggested solutions do not solve the problem, please contact your dealer or Service Center. Symptom Possible reason Corrective action The power supply • No voltage in the power socket in the wall. • Check that there is voltage in the power socket in the wall. or its switch LED •... - Page 15 Symptom Possible reason Corrective action Can not connect • The power supply is too far from the router • Please reset the power supply (disconnect the power cord), to your Wi-Fi®, and (weak signal) or your router is not working and wait 1 min.
