Energy Measurement Object (E4h)
Attr ID# Access Rule Name
28 Get Field rotation
29 Get Total Active energy(Sum
= Consumed –
Generated)
30 Get Total Reactive
energy(Sum =
Consumed – Generated)
31 Get Total Apparent energy
SCM-1202-023 Version 2.6
Data Type Element number:description
UINT64 0: Field rotation TS
FLOAT 1: Field rotation Value
UINT32 2: Reserved
UINT64 0: Consumed TS
FLOAT 1: Consumed Value
UINT32 2: Reserved
UINT64 3: Generated TS
FLOAT 4: Generated Value
UINT32 5: Reserved
UINT64 6: Sum TS
FLOAT 7: Sum Value
UINT32 8: Reserved
UINT64 0: Consumed TS
FLOAT 1: Consumed Value
UINT32 2: Reserved
UINT64 3: Generated TS
FLOAT 4: Generated Value
UINT32 5: Reserved
UINT64 6: Sum TS
FLOAT 7: Sum Value
UINT32 8: Reserved
UINT64 0: Consumed TS
FLOAT 1: Consumed Value
UINT32 2: Reserved
UINT64 3: Generated TS
FLOAT 4: Generated Value
UINT32 5: Reserved
UINT64 6: Sum TS
FLOAT 7: Sum Value
UINT32 8: Reserved
® ™
Anybus CompactCom 40 - PROFINET IRT
PROFIenergy Measurement ID
-
200
201
205
202
203
206
-
-
204
