Network Configuration Object (04h)
13.5.9. Instance Attributes (Instance #9, DNS1)
This instance holds the address to the primary DNS server. Changes are valid after reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
13.5.10. Instance Attributes (Instance #10, DNS2)
This instance holds the address to the secondary DNS server. Changes are valid after reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
13.5.11. Instance Attributes (Instance #11, Host name)
This instance holds the host name of the module. Changes are valid after reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
SCM-1202-023 Version 2.6
Access Data Type Description
Get Array of CHAR "DNS1"
(Multilingual, see page
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of UINT8 If read, the actual value will be received. If written, the written value is
reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of UINT8 Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Access Data Type Description
Get Array of CHAR "DNS2"
(Multilingual, see page
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of UINT8 If read, the actual value will be received. If written, the written value is
reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of UINT8 Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Access Data Type Description
Get Array of CHAR "Host name"
(Multilingual, see page
Get UINT8 07h (= CHAR)
Get UINT8 40h (64 elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of CHAR If read, the actual value will be received. If written, the written value is
reflected in attribute #6 until a reset.
Host name, 64 characters
Get Array of CHAR Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Host name, 64 characters
® ™
Anybus CompactCom 40 - PROFINET IRT
Multilingual Strings (page 103))
Multilingual Strings (page 103))
Multilingual Strings (page 103))
