Energy Measurement Object (E4h)
Attr ID# Access Rule Name
1 Get VoltagePH-N
2 Get Min VoltagePH-N
3 Get Max VoltagePH-N
4 Get VoltagePH-PH
5 Get Min VoltagePH-PH
SCM-1202-023 Version 2.6
Data Type Element number:description
UINT64 0: L1-N TS
FLOAT 1: L1-N Value
UINT32 2: Reserved
UINT64 3: L2-N TS
FLOAT 4: L2-N Value
UINT32 5: Reserved
UINT64 6: L3-N TS
FLOAT 7: L3-N Value
UINT32 8: Reserved
UINT64 9: Avg L-N TS
FLOAT 10: Avg L-N Value
UINT32 11: Reserved
UINT64 0: L1-N TS
FLOAT 1: L1-N Value
UINT32 2: Reserved
UINT64 3: L2-N TS
FLOAT 4: L2-N Value
UINT32 5: Reserved
UINT64 6: L3-N TS
FLOAT 7: L3-N Value
UINT32 8: Reserved
UINT64 9: Avg L-N TS
FLOAT 10: Avg L-N Value
UINT32 11: Reserved
UINT64 0: L1-N TS
FLOAT 1: L1-N Value
UINT32 2: Reserved
UINT64 3: L2-N TS
FLOAT 4: L2-N Value
UINT32 5: Reserved
UINT64 6: L3-N TS
FLOAT 7: L3-N Value
UINT32 8: Reserved
UINT64 9: Avg L-N TS
FLOAT 10: Avg L-N Value
UINT32 11: Reserved
UINT64 0: L1-L2 TS
FLOAT 1: L1-L2 Value
UINT32 2: Reserved
UINT64 3: L2-L3 TS
FLOAT 4: L2-L3 Value
UINT32 5: Reserved
UINT64 6: L3-L1 TS
FLOAT 7: L3-L1 Value
UINT32 8: Reserved
UINT64 9: Avg L-L TS
FLOAT 10: Avg L-L Value
UINT32 11: Reserved
UINT64 0: L1-L2 TS
FLOAT 1: L1-L2 Value
UINT32 2: Reserved
® ™
Anybus CompactCom 40 - PROFINET IRT
PROFIenergy Measurement ID
1
2
3
31
70
71
72
92
40
41
42
62
4
5
6
32
73
