Thank you for purchasing our product. Before installing/operating the product, read the instructions carefully and retain them
for future reference.
Attention!
● For installation, follow the steps described. Any damage caused by wrong installation shall be imputed to the users.
● To avoid a short circuit from occurring do not pull or modify the wires during installation.
● Do not disassemble or change any parts. Opening and dissassembling this unit will void any warranty.
● Maintenance and repairs should be executed by our professionals only.
Symbol description:
NOTE
Some procedures must be followed to avoid damages to the product.
WARNING!
Certain procedure must be followed to avoid damages to yourself, to the vehicle or to others.
1-1 Accessories
1
LCD meter X1
6
Velcro X1 set
1-2 Optional accessories ( infrared temp sensor extension wire)
1
Extension wire (6ft)
Part: BZ008000
2-1 Wiring Installation Instructions
IR
/ Temp
LCD meter(Accessory 1)
2
3
Meter cover X1
IR
/ Temp
7
8
Infrared temp sensor X1
2
3
Extension wire (10ft)
Part: BZ008001
Power wire
Temp sensor wire
4
Temp sensor extension
wire (3ft) X1
9
Bolted cover X1
Extension wire (15ft)
Part: BZ008002
Mid-way connector
Black / Ground wire connect to the vehicle body or
(Accessory 4)
the engine. (it must be a good ground)
(Accessory 3)
Infrared temp sensor(Accessory 7)
M3 X L20 screw X2(A)
5
Power wire X1
M3 X P0.5 nut X2(B)
M2x5LxP0.4 screw X6(A)
10
1.3 mm Allen key X 1
M3X5XP0.5 screw X2(B)
(A)
(B)
Red / "+"Wire connect key on
DC 12V main power switch
Flash
Light on
Hold the
Hold the
Button
Button
1 second
3 seconds
(B)
(A)
wh033ba26g
