Koso XR-01S Instructions Manual

Thank you for purchasing our product. This product is a multifunction meter and is easy to install. Before using, please read the instructions
●
carefully and retain them for future reference.
Attention!
● For installation, please follow the steps described. Any damage caused by wrong installation shall be imputed to the users.
● To avoid a short circuit from occuring do not pull or modify the wires during installation.
● Do not disassemble or change any parts. Opening and dissassembling this unit will void any warranty.
● Maintenance and repairs should be executed by our professionals only.
◎ Symbol description:
NOTE
Some procedures must be followed to avoid damages to the instrument.
WARNING! Certain procedures must be followed to avoid damages to yourself, to the vehicle or others.
1-1
Accessories
1
Meter X 1
M10 / S type speed
5
sensor bracket X 1
9
M4 X 10L screw X 2
1-2
Optional accessories
1
Active speed sensor
5
Meter bracket
2
Speed sensor X 1
M5 X 5L mm Hexagon
6
screw X 2
10
M5 washer X 2
2
Disc magnet screw
3
D6 X 5L mm magnet X 6
7
Meter bracket X 1
11
Mid-way connector X 10
3 L TYPE speed sensor
backet
FLASH LIGHT ON
HOLD THE HOLD THE
BUTTON ONE BUTTON 3
SECOND SECONDS
M8 / S type speed
4
sensor bracket X 1
8
M5 X 12L screw X 2
4
Meter bracket
