Robustel R3000 Quad Hardware Manual
Hardware Installation
1.
SIM Card Installation. Loosen the screws associated with the cover by using a screwdriver and then find the
SIM card slot/Micro SD card slot. Press the card with finger until you hear a click and then tighten the screws
associated with the cover by using a screwdriver. Put back the cover and tighten the screws associated with
the cover by using a screwdriver.
2.
Antenna Installation. Rotate the antenna into the antenna connector accordingly.
Cellular Antenna
3.
Mounting Kit installation. (Optional)
RT019_HM_R3000_Quad
DIN rail mounting
GPS Antenna
Wall mounting
9/11
