Robustel R3000 Quad Hardware Manual
NET Green
Yellow
Red
/
SIM
Green
Note: You can choose the display type of USR LED. For more details, please refer to
RT123_SM_RobustOS Software Manual Service > Advanced > System >System Settings > User LED Type.
3.

Reset Button.

Feature Operation
Reboot Press and hold the RST button for 2~ 5 seconds under the operating status.
Restore to default Press and hold the RST button for 5~10 seconds, the RUN LED starts blinking quickly, the router will restore to default
configuration configuration.
Restore to factory Once the operation of restoring default configuration is performed twice within one minute, the router will restore to factory
default settings default settings.
Note: The more details please refer to RT123_SM_RobustOS Software Manual, 2.3 Factory Reset.
4. Ethernet Ports. R3000 Quad Router has 4 Ethernet port with two LED indicators. The yellow one is link
indicator and the green one is speed indicator. For details about status, see the table below.
Indicator Status
Link indicator On, solid
On, blinking
Off
Speed indicator On, solid
Off
5. USB Interface.
Feature Operation
Firmware upgrade USB interface is used for batch firmware upgrading, but cannot be used for sending or receiving data from slave devices which
connected to it. You can insert a USB storage device into the router's USB interface, such as a U disk or a hard disk. If there have a
supported configuration file or a router firmware in this USB storage device, the router will automatically update the
configuration file or the firmware. For more details, see RT123_SM_RobustOS Software Manual.
RT019_HM_R3000_Quad
On, solid
On, solid
On, solid
Off
On, solid
On, blinking
Off
Description
Connection is established
Data is being transferred
Connection is not established
100 Mbps mode
10 Mbps mode
Connection to 4G network is established
Connection to 3G network is established
Connection to 2G network is established
Connection to network is not established or establishing
Main card is being used
Backup card is being used
NO SIM card
