3. Specifications

3.1. Specifications
■Product specifications
Fluid
Operating temperature range[°C]
Connector type
Common
Weight [g]
Max. workload [kg] Note2)
Impact / Vibration resistance [m/s
Air supply port(P)
Power supply voltage
Max. vacuum pressure [kPa] note4)
Max. suction flow [L/min(ANR)] note4)
Vacuum
Air consumption [L/min(ANR)] note4)
ejector
Supply pressure range [MPa]
Standard supply pressure [MPa] note5)
Valve Model
Model
Rated pressure range [kPa]
Pressure
Display Accuracy [%]
switch
Repeatability [%]
Temperature characteristics [%]
Applicable suction cups
Note 1) The weight changes by the selected suction cup. Refer to "3.4 How to order".
Note 2) Limited by the cup diameter, mounting orientation or workpiece. The weight of the workpiece shall be maximum
workload or less.
Gripping or transfer of workload exceeding the maximum workload leads to the decrease of vacuum due to air leakage.
Note 3) Impact resistance: The characteristics are satisfied after tested one time in each of the X, Y and Z directions without
energization. (Initial value)
Vibration resistance: The characteristics are satisfied after tested a one sweep in each of the X, Y and Z directions at 10
to 500 Hz without energization. (Initial value)
Note 4) Values at the standard supply pressure. Values are based on standard of SMC measurements. They depend on
atmospheric pressure (weather, altitude, etc.) and measurement method.
Note 5) This shows the pressure just before the supply (P) port.
The performance such as vacuum pressure may reduce, depending on supply air capacity, the piping volume (piping
length and diameter) and affection of air consumption of other devices which operate at the same time.
