2. Names of Parts of the Product
Internal details
Air supply port
Robot connector
Parallel pin
Robot mounting flange
Digital pressure switch
O-ring
Parallel pin
Cup mounting flange
(With mesh)
(Compliant with ISO 9409-1-50-4-M6)
Suction cups with adapter
-7-
No. TQ1230001-OM104-A
