2. Names of Parts of the Product

Parallel pin (6x10)
Robot mounting flange
（Compliant with "ISO9409-1-50-4-M6"）
Hexagon socket head cap
screw (M6x10)
Air pressure supply port
Applicable tubing O.D.:
Φ6
Cover
M8 Connector cable
Hexagon socket head cap
screw (M6x10)
Parallel pin (6x10)
O-ring
Cup mounting flange
（Compliant with "ISO9409-1-50-4-M6"）
Hexagon socket head cap
screw (M6x10)
Suction cups with adapter
-7-
No. TQ1230001-OM101-C
